11
a piece of scrap wood to the back of your work piece or
continue the hole from the back of the wood when the
drill bit rst breaks through.
4. Masonry drilling.
For maximum performance use carbide-tipped masonry
impact bits when drilling holes in medium speed for best
results in brick. When drilling holes in tile, practice on a
scrap piece to determine the best speed and pressure.
INSTALLING/REMOVING BITS AND DRILLS
1. Installing bits/drills
Lock the switch trigger by placing the direction of rotation
selector in centre position. Open or close chuck jaws to a
point where the opening is slightly larger than the bit size
you intend to use. Also, raise the front of the drill slightly
to keep the bit from falling out of the
chuck jaws. Insert drill bit straight into chuck the full
length of the jaws as shown in. Tighten the chuck jaws on
the drill bit.
WARNING: Make sure to insert drill bit straight
into chuck jaws.
Do not insert drill bit into chuck jaws at an angle, this
could cause drill bit to be thrown from drill resulting in
possible serious personal injury or damage to the chuck.
2. Removing bits/drills
• Lock the switch trigger by placing rotation selector in
centre position.
• Loosen the chuck jaws from the drill bit.
Note: Rotate chuck body in the direction of the arrow
marked. Release to loosen chuck jaws.
• Do not use a wrench to tighten or loosen the chuck jaws.
• Remove the drill bit from the chuck jaws.
DISPOSAL
Discarded electric appliances are recyclable and
should not be discarded in the domestic waste!
Please actively support us in conserving resources
and protecting the environment by returning this
appliance to the collection centres (if available).
Made in China.
FRANÇAISFR
PERCEUSE / VISSEUSE SANS FIL
INTRODUCTION
L’outil électroportatif est conçu pour le vissage et le dévis-
sage de vis ainsi que pour le perçage du bois, du métal, de
la céramique et des matières plastiques.
SPECIFICATIONS TECHNIQUES (FIG. 1)
Tension de la batterie /
Capacité d’alimentation de la
batterie de stockage
21 V / 1,5 Ah
Type de batterie Li-Ion
Nombre de batteries 2 pcs
Couple maximum 50 Nm
Nombre de vitesses 2
Temps de charge de la
batterie
1,5 h
Réglage du couple 20 + 1
Vitesse à vide 1 0 - 350 tr / min
Vitesse à vide 2 0 - 1 350 tr / min
Diamètre maximum de foret:
métal
10 mm
Diamètre maximum de foret:
bois
23 mm
Arrêt rapide +
Éclairage de la zone de travail +
Sens inverse +
Poids du produit 1,1 kg
ORGANISATION DE L’APPAREIL (FIG. 2)
1. Changer;
2. Bouton de marche arrière;
3. Lumière LED;
4. Bouchon de couple;
5. Mandrin;
6. Batterie;
7. Bouton de libération de la batterie;
8. Bouton de changement de vitesse à deux vitesses.
