English 13
7 Unlocking button
8 Battery pack release
9 Type plate
10 Power switch
11 Shaft release
12 Upper shaft
13 Reel cover release
14 Reel cover
15 Cutting tool
a) String reel
b) *Trimmer blade
16 Button for releasing the string
17 Eye
18 *Quick Charger Battery Power 18 V
19 *Standard Charger Battery Power 18 V
20 *Rechargeable battery pack
* optional
Rechargeable battery pack
The device can be operated with a Kärcher 18 V Bat-
tery Power battery pack.
Installation
Installing the string guard
몇 WARNING
Blade on the string guard
Incision injuries
Install the string guard before using the device for the
first time.
몇 WARNING
Exposed string
Incision injuries
Never use the device without the string guard.
Illustration B
The string guard must face the operator.
1. Insert the string guard into the bracket.
2. Screw the string guard to the bracket.
Installing shaft
1. Connect the upper and lower shaft segments.
Illustration C
Initial startup
Adjusting the string length
1. Press the button for releasing the string and pull the
string out of the string reel and up to the cutting
edge.
Illustration D
Installing the battery pack
1. Push the battery pack into the mounting in the de-
vice until it audibly latches into place.
Illustration E
Operation
Working techniques
몇 CAUTION
Obstacles in the mowing area
Risk of injury and damage
Before starting mowing, check the work area for objects
that may be flung away, e.g. wires, stones, cords or
glass.
1. Press the unlocking button.
Illustration F
2. Press the power switch.
The device starts up.
3. Guide the cutting head parallel to the ground.
4. Guide the device in a semi-circular movement over
the cutting area.
5. Mow long grass in several passes.
Extending the string length during operation
The string on the device wears during mowing and be-
comes shorter due to fraying and being torn off. A string
that is too short will result in unsatisfactory mowing re-
sults.
Note
The string length can be extended during operation.
1. Release the unlocking button and power switch.
Illustration G
2. Press the unlocking button and power switch.
The string extends automatically and is automatical-
ly trimmed to the correct length by the cutting blade.
Illustration H
Note
You must replace the string reel if the string no longer
extends automatically (see Chapter Replacing the
string reel).
Mowing edges
1. Remove the battery pack (see Chapter Removing
the battery pack).
2. Press the shaft release.
Illustration I
3. Turn the shaft by 180°.
4. Mount the battery pack (see Chapter Installing the
battery pack).
5. Press the unlocking button.
6. Press the power switch.
7. Mow the edge regions.
Illustration J
Changing the cutting tool
The string reel and the trimmer blade are available as
cutting tools.
1. Remove the battery pack (see Chapter Removing
the battery pack).
2. Remove the unneeded cutting tool and fit the de-
sired cutting tool (see Chapter Replacing the cutting
tool).
Removing the battery pack
Note
During longer work breaks, remove the battery pack
from the device and secure it against unauthorised use.
1. Pull the battery pack unlocking button in the direc-
tion of the battery pack.
Illustration K
2. Press the battery pack unlocking button to unlock
the battery pack.
3. Remove the battery pack from the device.
