Specifications

CPU

∙ Supports 12th/ 13th Gen Intel® Core™ Processors,

Pentium® Gold and Celeron® Processors*

∙ Processor socket LGA1700

* Please go to www.msi.com to get the newest support status as new processors

are released.

Chipset Intel® Z790 Chipset

Memory

∙ 4x DDR5 memory slots, support up to 192GB*

∙ Supports 1R 5600 MHz (by JEDEC & POR)

∙ Max. overclocking frequency:

• 1DPC 1R Max speed up to 7200+ MHz

• 1DPC 2R Max speed up to 6600+ MHz

• 2DPC 1R Max speed up to 6400+ MHz

• 2DPC 2R Max speed up to 5600+ MHz

∙ Supports Intel® XMP 3.0 OC

∙ Supports Dual-Controller Dual-Channel mode

∙ Supports non-ECC, un-buffered memory

* Please refer to www.msi.com for more information on compatible memory.

Expansion Slots

∙ 2x PCIe x16 slots

• PCI_E1 slot (From CPU)

• Supports up to PCIe 5.0 x16

• PCI_E3 slot (From Z790 Chipset)

• Supports up to PCIe 4.0 x4

∙ 1x PCIe 3.0 x1 slot

• PCI_E2 slot (From Z790 Chipset)

• Supports up to PCIe 3.0 x1

Onboard Graphics

∙ 1x HDMI™ 2.1 port with HDR, supporting a maximum

resolution of 4K 60Hz*/ **

∙ 1x DisplayPort 1.4 port with HBR3, supporting a maximum

resolution of 8K 60Hz*/ **

* Available only on processors featuring integrated graphics.

** Graphics specifications may vary depending on the CPU installed.

Continued on next column
