Continued from previous column

SATA Ports

∙ 7x SATA 6Gb/s ports

• SATA_1, SATA_5~6 & SATA_7~8 (From Z790 chipset)

• SATA_A1~A2 (From ASM1061)

M.2 SSD Slots

∙ 4x M.2 slots (Key M)

• M2_1 slot (From CPU)

• Supports up to PCIe 4.0 x4

• Supports 2260/ 2280/ 22110 storage devices

• M2_2 slot (From Z790 chipset)

• Supports up to PCIe 4.0 x4

• Supports 2260/ 2280 storage devices

• M2_3* slot (From Z790 chipset)

• Supports up to PCIe 4.0 x4

• Supports up to SATA 6Gb/s

• Supports 2242/ 2260/ 2280 storage devices

• M2_4 slot (From Z790 chipset)

• Supports up to PCIe 4.0 x4

• Supports 2242/ 2260/ 2280 storage devices

* SATA_1 will be unavailable when installing M.2 SATA SSD in the M2_3 slot.

RAID

∙ Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA

storage devices*

∙ Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2

NVMe storage devices

* SATA_A1~A2 do not support RAID function.

Audio

Realtek® ALC4080 Codec

∙ 7.1-Channel USB High Performance Audio

∙ Supports up to 32-bit/384kHz playback on front panel

∙ Supports S/PDIF output

LAN ∙ 1x Intel® 2.5Gbps LAN controller

Continued on next column
