Continued from previous column

Wi-Fi & Bluetooth®

Intel® Wi-Fi 6E

∙ The Wireless module is pre-installed in the M.2 (Key-E)

slot

∙ Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz*(160MHz)

up to 2.4Gbps

∙ Supports 802.11 a/ b/ g/ n/ ac/ ax

∙ Supports Bluetooth® 5.3**, FIPS, FISMA

* The usage of Wi-Fi 6GHz band relies on Windows 11 support and depends on

every country’s regulations.

** The Bluetooth version may be updated, please refer to the Wi-Fi chipset

vendor’s website for details.

Power Connectors

∙ 1x 24-pin ATX main power connector

∙ 2x 8-pin +12V power connectors

Internal USB

Connectors

∙ 1x USB 3.2 Gen 2 10Gbps Type-C front panel connector

(From Z790 chipset)

∙ 1x USB 3.2 Gen 1 5Gbps connector (From Hub GL3523)

• Supports additional 2 USB 3.2 Gen 1 5Gbps ports

∙ 2x USB 2.0 Type-A connectors (From Hub GL850G)

• Supports additional 4 USB 2.0 ports

Fan Connectors

∙ 1x 4-pin CPU fan connector

∙ 1x 4-pin water-pump fan connector

∙ 6x 4-pin system fan connectors

System Connectors

∙ 1x Front panel audio connector

∙ 2x System panel connectors

∙ 1x Chassis intrusion connector

∙ 1x TPM module connector

∙ 1x Tuning controller connector

∙ 1x TBT connector (supports RTD3)

Jumpers

∙ 1x Clear CMOS jumper

∙ 1x OC safe boot jumper

LED Features

∙ 1x 4-pin RGB LED connector

∙ 3x 3-pin ARGB Gen2 LED connectors

∙ 4x EZ Debug LED

Continued on next column
