Français 17
Troubleshooting guide
Malfunctions often have simple causes that you can
remedy yourself using the following overview. When in
doubt, or in the case of malfunctions not mentioned
here, please contact your authorised Customer Service.
The device does not start up
Battery is empty.
Charge the rechargeable battery.
Battery is not inserted correctly.
Push the battery into the mount until it locks into
place.
Battery is defective.
Replace the battery.
The battery is not charging
The charging plug/mains plug is not connected correct-
ly.
Connect the charging plug/mains plug correctly.
The socket is defective.
Check that the socket is working.
The wrong charger is being used
Check that the correct charger is being used.
The device stops during operation or the suction
performance is poor
The battery has overheated.
Stop work and wait until the battery temperature is
back in the normal range.
The accessories, the suction opening on the dust con-
tainer or the suction pipes are clogged.
Remove the clog with a suitable aid.
The dust container is full.
Empty the dust container.
The filters are soiled.
Clean the filters, see chapter Care and service.
Roller brush is blocked.
Remove any blockage.
The LED indicator lamp for the suction channel and
/ or floor nozzle flashes red
Illustration AF
Blockage in the suction channel due to bulky objects /
particles.
Remove the clog with a suitable aid.
The dust container is full.
Empty the dust container.
The filters are soiled.
Clean the filters, see chapter Care and service.
Blockage in the floor nozzle due to bulky objects / parti-
cles.
Remove the clog with a suitable aid.
Brush roll has got caught in long carpet fringes.
Wear the device to separate the floor nozzle from
the carpet
.
Abnormal engine noise
The accessories, the suction opening on the dust con-
tainer or the suction pipes are clogged.
Remove the clog with a suitable aid.
Technical data
Subject to technical modifications.
Contenu
Remarques générales
Veuillez lire le présent le manuel d'ins-
tructions original et les consignes de sé-
curité jointes avant la première
utilisation de l'appareil. Suivez ces instructions.
Conservez les deux manuels pour une utilisation ulté-
rieure ou pour le propriétaire suivant.
Utilisation conforme
● Utiliser l'appareil uniquement pour un usage ména-
ger privé.
● L’appareil est exclusivement destiné au nettoyage
de surfaces
sèches.
● L'
utilisation suivante est considérée non conforme :
– Aspiration sur des personnes, des animaux, des
plantes ou des vêtements portés sur le corps.
– Aspiration d’eau ou d’autres liquides.
– Aspiration de cendres incandescentes, de char-
bon, de cigarettes ou d’autres substances com-
bustibles ou facilement inflammables.
– Utilisation à proximité de substances explosives
ou facilement inflammables.
Electrical connection
Voltage of charger V 25,2
Nominal power W 250
Battery pack type Li-ION
Charger 30 V
TEK
Model YLS0241A-
E300060
Part number 9.754-741.0
Nominal voltage of charger V 100 -
240
Frequency Hz 50 - 60
Charging time when the battery is
completely discharged
min 235
Protection class II
Device performance data
Tank content l 0,8
Operating time when battery is ful-
ly charged in normal operation
min 50
Operating time in maximum mode
when battery fully charged
min 12
Dimensions and weights
Weight (without accessories) kg 1,7
Remarques générales......................................... 17
Utilisation conforme............................................. 17
Protection de l'environnement............................. 18
Accessoires et pièces de rechange .................... 18
Garantie .............................................................. 18
Etendue de livraison............................................ 18
Description de l'appareil...................................... 18
Montage du support mural/de la station de sta-
tionnement indépendante avec fonction de
charge ................................................................. 18
Mise en service ................................................... 19
Utilisation............................................................. 20
Utilisation des accessoires.................................. 21
Transport............................................................. 21
Stockage ............................................................. 21
Entretien et maintenance .................................... 21
Dépannage en cas de défaut.............................. 23
Caractéristiques techniques................................ 23
