ELECTRIC IMPACT DRILL

Main connection

ATTENTION!

Power tools should only be connected to single-phase AC power, the voltage of which

corresponds to the voltage indicated on the rating plate located on the tool housing. If the

rating plate indicates a voltage of 230V, then the power tool can also be switched on to a main

with a voltage of 220 V.

When working outdoors use industrial extension cords intended for outdoor use. Do not use homemade

extensions. When working outdoors connect power tools to the power circuit equipped with a dierential

automatic with a response current of not more than 30 мА, this will reduce the risk of electric shock.

When connecting ensure that the insulation of the electrical cable and the power plug of the machine is intact.

Make sure the machine's power switch is in the “o” position.

This power tool can be connected to power outlets that do not have a protective ground, since it has double

insulation (protection class II).

Spindle speed adjustment

Depending on the type of the tooling used, the type of material being processed and the nature of processing,

you can choose the optimum spindle speed of the machine. Adjustment is carried out from the minimum

to the maximum value (Section 4, Table 1) by changing the effort of pressing the key 9 (pic. 1) of the switch.

You can change the speed when the engine is running, including under load. Key 9 of the switch can be locked

in the “on” position by pressing the xing button 6 (pic. 1). To unlock key 9, you need to click on it again.

The key stroke of the switch and, accordingly, the maximum spindle speed of the machine can be adjusted

by using the setting-ring 10 (pic. 1). When the switch 9 is locked in the "on" position (pic. 1), the spindle speed

of the machine can be adjusted by rotating the setting-ring 10 (pic. 1).

ATTENTION!

Do not overload the machine operating at reduced speeds. Decreasing the engine rotor speed

impairs the cooling of the machine.

Reversing spindle rotation

Spindle rotation direction can be changed from right to left and back if necessary, for example, when using left-

handed drills or grinding tooling. Switching the direction of rotation is carried out using switch 5 (pic. 1), located

above the key switch. Switching must be performed only after the engine has completely stopped and when

the switch key 9 (pic. 1) is in the "o" position.

ATTENTION!

It is not recommended to use a drilling machine for screwing and unscrewing screws as long

work at low rotation may lead to overheating of the engine.

Enable impact mode

To increase the drilling eciency of hard and brittle materials such as bricks, concrete, etc. the machine is equipped

with an impact function. To activate the impact function, move the mode switch 3 (pic. 1) to the position marked

with:

Switching can be done regardless of whether the engine is on or not. To deactivate the impact function move

the switch to the position marked:
