DESCRIPTION

SAFETY SYSTEM

BEFORE FIRST USE

USING THE APPLIANCE

A Pusher

B Feed tube

C Cover

D Sieve

E Juice collector

F Pouring spout

G Pulp collector

H Safety clamp

I Control knob (2 speeds)

J Drive shaft

K Motor unit

L Juice jug cover

M Juice jug

N Foam separator

O Cleaning brush

CAUTION: the safety precautions are part of the appliance. Read them carefully before using

your new appliance for the ﬁrst time. Keep them in a place where you can ﬁnd and refer

to them later on.

This appliance is ﬁtted with a safety mechanism. To start the juice machine, the cover (C) must

be properly secured by the safety clamp (H). Opening the safety clamp (H) will stop the juice

machine. At the end of a cycle, place the control knob (I) to 0 and wait until the sieve (D) stops

completely before removing the cover.

• We recommend that you wash all the removable parts (A, B, C, D, E, G, L, M, N) in warm soapy

water (see paragraph “Cleaning”). Rinse and dry them carefully.

• Unpack the appliance and place it on a clean, dry stable ﬂat work surface away from water

splashes.

• Ensure that all packaging has been removed before starting the appliance.

• Place the juice collector (E) on the body of the appliance (see Fig. 1).

• Place the sieve (D) in the juice collector (E). Ensure that the sieve is properly clipped onto

the drive shaft (J) (see Fig. 2).

• Fit the pulp collector (G) on the rear of the appliance (see Fig. 3).

• Fit the cover (C) on the appliance, spout to the rear (see Fig. 4).

• Push the safety clamp (H) to the rear until it locks into place. You will hear an audible “click”

(see Fig. 5).

• Slide the pusher (A) into the feed tube (B) aligning the groove on the pusher with the small

ridge in the feed tube (see Fig. 5).

• The juice jug (M) has a foam separator (N) that keeps the foam in the jug when you pour the

juice into a glass. If you do not want to separate the foam, remove the foam separator (N).

• Place the juice jug (M) under the pouring spout in front of the appliance (see Fig. 6).

• Plug in the appliance.

• To start the appliance, use the control knob (I).

• Insert the fruits or vegetables through the feed tube (B).

• Please rotate the pouring spout (F) for anti-drip function.

• The fruits and vegetables must be inserted only while the motor is running.

• Do not press too hard on the pusher (A). Do not use any other utensil. NEVER push with your ﬁngers.

• When you have ﬁnished, stop the appliance by turning the control knob (I) to 0 and wait until

the sieve (D) stops completely.

• When the pulp collector (G) is full, or the juice ﬂow slows down, empty the pulp collector and

clean the sieve and the cover.

• Remove the “juice collector + sieve” assembly by pulling vertically using both hands

(see Fig. 7 and 8).

WHICH SPEED TO USE?

It is recommended that you use the appliance for no more than 2 minutes continuously.

* The quality and quantity of juice varies greatly according to the freshness when harvested and the particular

variety of fruit or vegetable. The quantities of juice indicated above are therefore approximate.

Ingredients Speed Approx. weight (in kg)

Quantity of juice

obtained in ml (*)

Apples 2 1 650

Pears 2 1 600

Carrots 2 1 600

Cucumbers 1 1 (about 2 cucumbers) 600

Grapes 1 1 450

Tomatoes 1 1.5 900

Celery 2 1.5 350

Orange

1 650

Choosing the wrong speed may cause the appliance to vibrate abnormally.

PRACTICAL TIPS

• Wash the fruit carefully before stoning.

• In general, you do not need to remove the skin or peel. You only need to peel fruit with thick

and bitter skin, like lemon, orange, grapefruit.

• It is difﬁcult to extract juice from bananas, avocados, blackberries, ﬁgs, aubergines and

strawberries.

• Choose fresh, ripe fruit and vegetables, they will yield more juice. This appliance is suitable

for such fruits as apples, pears, oranges, grapes, pomegranates and such vegetables as carrots,

cucumbers, tomatoes, beetroot and celery.

• If you use overripe fruits, the sieve will get clogged more quickly and less juice will be

extracted.

• Important: All juice must be consumed immediately. On contact with air, it is very quickly

oxidised, which can change its taste, colour and nutritional value. Apple and pear juices

quickly turn brown. Add a few drops of lemon juice to slow this discoloration.
