169
RAID I20
DISKx Formatting
Formatting hard drive x. -
RAID I21
DISKx Checking
Checking hard drive x. -
RAID I22
DISKx 0 Filling
Erasing the data for hard drive x. -
SYSTEM I25
F/WUPDATING
Updating the TeraStation firmware.
Note: Do not turn off the power during
the updating process.
-
Web Setting I26
Initializing
Initializing all settings. -
USB Diskx I27
Checking
Checking USB hard drive x. -
USB Diskx I28
Formatting
Formatting USB hard drive x. -
Press FuncSW I31
New Diskx ready
Displayed when pressing the Function
button to rebuild the RAID after replacing
hard drive x.
Press the Function button to rebuild the
RAID array.
Set From Web I32
New Diskx ready
Displayed after replacing hard drive x
when the RAID needs to be rebuilt in
Settings or formatting is necessary.
In Settings, either rebuild the RAID array or
format the hard drive.
Replication I33
ReplicateFailure
An error occurred in replication, or
synchronization between the main
TeraStation and the backup TeraStation
failed during failover configuration.
In Settings, navigate to Backup - Replication
and choose "Resync" to execute
resynchronization. If the error is displayed
again, contact Buffalo technical support for
assistance.
Virus alert I34
Virus detected
A virus scan found a virus.
Once the virus is removed from the
quarantine folder, the message is no
longer displayed. If the antivirus software
is configured to delete viruses from the
quarantine folder automatically, then the
message will not be displayed.
Cartridgex I35
Location error
A hard drive set as a media cartridge has
been installed in the drive x slot.
Connect to the slot that was set as a media
cartridge.
Cartridgex I36
Decryption error
Media cartridge cannot be decrypted.
The media cartridge may have been
encrypted by a TeraStation other than
this product.
Connect to the TeraStation that performed
encryption to decrypt.
Recovery I37
SystemRecovering
System recovery in progress. -
Recovery I38
RecoveryFinished
System recovery is complete. -
Recovery I39
Change Boot
System recovery from the USB recovery
device is complete.
Change the boot mode switch on the rear
to HDD.
Recovery I40
DataWillDeleted
Beginning recovery. All data in the drive 1
will be deleted.
-
Recovery I41
PushFuncToStart
Pressing the function button on the front
will start the recovery process.
-
Recovery I42
Preparing
Preparing to start the recovery process. -
Recovery I43
Unsupported HW
The TeraStation was started from the USB
recovery device, but the system cannot
be recovered from this USB recovery
device.
-
