Buffalo TS5600D2406 [57/176] Creating and expanding volumes

3 Click Yes.

4 Select the TeraStation to be disconnected from "Target", then click Unregister iSCSI Device.

Note: When connecting to the TeraStation from multiple computers, follow the above procedure to remove the

registration from each computer.

5 Disconnect the Ethernet cable of the TeraStation.

The TeraStation is now disconnected.

To disconnect multiple volumes in a single operation, follow the procedure below.

(1) Start the iSCSI Connection Tool.

(2) Click Setup - Remove the registered iSCSI Hard Disk.

(3) Select the IP address (port number) of each TeraStation that you want to disconnect and click Remove.

Creating and Expanding Volumes

Creating an iSCSI Volume

Up to 32 iSCSI volumes are supported. Each individual iSCSI volume can be connected to different computers (a

single iSCSI volume cannot be connected to multiple computers).

Notes:

• When an iSCSI volume is deleted, all data contained in the iSCSI volume is erased. Before changing settings,

back up any important data.

• Enable LVM (previous page) to delete or create volumes.

1 In Settings, click Drives.

2 Click to the right of "iSCSI".

3 Click Create Volume.

4 Choose a name, description, volume, and size, then click OK.

5 Enter the confirmation number and click OK.

6 Click Close.

Note: Before using, connect the new volume with an iSCSI connection tool and format the volume from within
