172
Internal Hard Drive
If a hard drive in the TeraStation malfunctions, replace it with a Buffalo drive
of the same capacity. Use a Buffalo OP-HDWR series drive for the TS5200DS,
a OP-HDH series drive for the TS5400RH, and a OP-HDS series drive for
other TS5000 series TeraStations. The drives listed above are available from
www.buffaloamericas.com.
Power Supply AC 100–240 V, 50/60 Hz
Dimensions (D x W x H)
TS5800D: 230 x 300 x 215 mm; 9.1 x 11.8 x 8.5in
TS5600D: 230 x 170 x 260 mm; 9.1 x 6.7 x 10.2 in
TS5400D: 230 x 170 x 215mm; 9.1 x 6.7 x 8.5 in
TS5400R, TS5400RH: 430 x 45 x 430 mm; 16.9 x 1.7 x 16.9 in
TS5200D, TS5200DS: 230 x 170 x 170 mm; 9.1 x 6.7 x 6.7 in
Weight
TS5800D: Approx. 12.0 kg; 26.5 lb
TS5600D: Approx. 10.0 kg; 22.1 lb
TS5400D: Approx. 7.5 kg; 16.5 lb
TS5400R, TS5400RH: Approx. 9.0 kg; 19.8 lb
TS5200D, TS5200DS: Approx. 4.0 kg; 8.8 lb
Power Consumption (Max.)
TS5800D: 170 W
TS5600D: 120 W
TS5400D: 86 W
TS5400R, TS5400RH: 140 W
TS5200D, TS5200DS: 47 W
Operating Environment
Temperature: 5–35°C; 41–95°F
Environment Humidity: 20–80% (no condensation)
Compatibility
Windows PCs, Macs, and tablets with wired or wireless Ethernet connection.
Note: The TeraStation requires a network connection with your computer
for operation. It cannot be connected via USB.
Supported OS
Windows 8.1
*
, Windows 8
*
, Windows 7
*
, Windows Vista
*
, Windows XP,
Windows XP Media Center Edition (2004 or 2005), Windows Server 2012,
Windows Server 2008 R2, Windows Server 2008, Windows Server 2003 R2,
Windows Server 2003, Windows 2000 Server, Windows RT 8.1, Windows RT
OS X 10.9, 10.8, 10.7, 10.6, 10.5, 10.4, 10.3.9
*32-bit and 64-bit
Models
TS5200D0202, TS5200D0402, TS5200D0402V5, TS5200D0602, TS5200D0802, TS5200D
TS5400D0404, TS5400D0804, TS5400D0804V5, TS5400D1204, TS5400D1604, TS5400D
TS5400R0404, TS5400R0804, TS5400R1204, TS5400R1604, TS5400R1604V5, TS5400R
TS5400RH0804, TS5400RH1204, TS5400RH1604, TS5400RH2404
TS5600D0606, TS5600D1206, TS5600D1806, TS5600D2406, TS5600D1206V5, TS5600D
TS5800D0808, TS5800D1608, TS5800D2408, TS5800D3208, TS5800D3208V5, TS5800D
TS5200D0202S, TS5200D0402S, TS5200D0802S
