5 Power Switch

Move the switch up and down to power on and off.

6 USB 2.0 Port

Compatible Buffalo USB hard drives, USB flash drives, digital cameras, USB UPS connection, and USB printers

can be connected. USB hubs are not supported.

7 Power Connector

Use the included power cable to connect to a surge protector or outlet.

8 Anti-Theft Security Slot

Use this slot to secure your LinkStation with a cable lock (not included).

9 LAN Port

Connect to a router, hub, or switch on your Ethernet network with the included Ethernet cable.

10 Hook

To secure the power cable, insert it into the slot as shown.

11 Disk 1 Error LED (LS420D, LS420DS, and LS421DE only)

If there is a hard drive error on drive 1, this LED will light.

12 Disk 2 Error LED (LS420D, LS420DS, and LS421DE only)

If there is a hard drive error on drive 2, this LED will light.

13 USB 3.0 Port (LS421DE only)

Compatible Buffalo USB 3.0 hard drives can be connected. USB hubs are not supported.

Notes:

• The USB 3.0 port doesn't support isochronous transfers when the USB device server is enabled.

• With Mac OS, only the USB 2.0 ports work with the USB device server.

14 Link and Activity LED

This LED shows network activity. It blinks green when the LinkStation is accessed over the network.

15 Not in use.

Changing Admin Password and Adding a Shared Folder

After initial setup, changing your password and creating other shared folders are recommended.

1 Double-click the icon to start NAS Navigator2.

2 Right-click on your LinkStation's icon and select Settings. On the Mac, select the LinkStation's icon while
