APPEARANCE (see fig. A on p. 2) ENG

① – adjustable headband; ② – volume control wheel; ③ – mute button; ④ – microphone;

⑤ – 3.5 mm AUX cable (2 m).

TECHNICAL SPECIFICATIONS

Intended purpose. Lorgar Noah 101 gaming headset is an over-the-ear closed-back headset

with a retractable microphone. The headset is designed for audio input and output while

playing games, making voice calls and working in various apps. Compatible with PCs, gaming

and mobile devices, etc.

Models. LRG-GHS101B (black), LRG-GHS101W (white).

Design features. 185×195×80 mm, 245 g; ABS plastic, polyurethane.

Functional features. Connection: 3.5 mm AUX cable. Microphone: retractable,

omnidirectional, −42 dB, 100–3000 Hz. Speakers: Ø 40 mm, 113 dB, 20–20,000 Hz, 32 Ohms,

20 mW (up to 35 mW). Operating conditions: temp. 0…+45 °C, RH 45–75 % (non-condensing).

Package contents: LRG-GHS101 gaming headset, adapter, quick start guide.

SAFE USE GUIDELINES

To avoid hearing damage, set the volume to minimum before using the headset. Do not use the

headset at high volume for a long time. Do not use the headset while driving. Do not expose the

headset to high temperatures (from heating appliances or direct sunlight), high humidity, avoid

exposure to dust and liquids. Clean only after disconnecting from the power supply and only using

a dry or slightly damp cloth, without any detergents or cleaning agents. Do not drop the headset,

disassemble or repair it yourself.

OPERATION

Connection. Via the cable: see fig. B-1 on p. 2.

Via the adapter: see fig. B-2 on p. 2. Headphones and microphone will not work

simultaneously if the line out and microphone jacks on the device * are two separate jacks

rather than one. In this case, first connect the headset to the adapter, then connect the

adapter to the line out and microphone jacks on the device *.

Volume level adjustment. The volume level is adjusted by scrolling the volume control wheel

(see fig. C on p. 2).

Microphone control. Pressing the mute button once allows to turn the microphone on/off

(see fig. C on p. 2).

TROUBLESHOOTING

The headset isn't working. Make sure that the headset is selected for audio input and output

in the settings of the device * or the app that you are using. Check volume levels on the

headset and on the device *. Check microphone sensitivity levels in the settings of the

device * or the app that you are using. Check system settings that may be limiting microphone

operation. Make sure that the cable is connected correctly and is not damaged. If the headset

is not working properly, contact customer support (email: support@lorgar.eu; online chat:

lorgar.com; feedback form: lorgar.com/for-users).

ADDITIONAL INFORMATION

The information contained herein is subject to change without notice to users. Up-to-date

information and detailed description, connection and operation steps, certificates, warranty

conditions are available in the complete user manual at lorgar.com/drivers-and-manuals.

Manufacturer: ASBISc Enterprises PLC, Iapetou, 1, Agios Athanasios, 4101 Limassol, Cyprus.

Made in China. All mentioned trademarks and brand names are the property of their respective

owners.

* Device – PC, laptop, tablet, etc.
