Playback

Press the Photo/Video/Playback button (19) to switch to playback mode. The icon

in the upper le corner of the screen will change in conrmation. Select the desired

photo or video clip with UP (18) and DOWN (21) buttons and press OK (20) to play it.

Deleting les

When browsing saved les, press the Setup button (16), select Delete… and press

OK (20) to conrm selection (you can choose to delete everything or just the selected

le from the displayed menu).

Protecting les

When browsing saved les, press the Setup button (16), select Protect and press OK

(20) to conrm selection (you can choose to protect everything or just the selected

le from the displayed menu).

Zoom

Scroll the zoom adjustment wheel (2) to zoom your view in or out.

Polarizing lter

You can use a polarizing lter to reduce light reection while observing objects with

a shiny surface like metal, crystals, etc. Rotate the polarizing wheel (3) by

90 degrees to activate or deactivate the polarizing eect.

Mass storage on PC

Insert a microSD card in the slot. Connect the microscope to your PC with the USB

cable to download images from the card to your computer.

Preview on PC

Only works with the soware installed. Remove the microSD card from the slot.

Connect the microscope to your PC with the USB cable.

Connecting the microscope to a TV-set

Plug the AV cable into the microscope and connect it to your TV-set (refer to the

User Guide of your TV-set for additional information). Turn on the TV and select the

correct channel from the corresponding menu of the TV-set (refer to the User Guide

of your TV-set for additional information).

Attaching the tripod

Place the tripod on a stable surface. Connect the tripod to the threaded hole (9)

on the microscope and rotate the microscope until it locks in place. Do not apply

excessive pressure during rotation, as this may damage both the microscope and

the tripod. Tripod height may be adjusted, if necessary.

Display menu

Press Setup button (16) to open the main display menu. From this menu you

can set image and video resolution, the interface language, date and time, turn

on the power saving mode, set up the TV connection, format the SD card, reset

settings and check the hardware version. Also, this menu provides access to the Loop

recording mode and Date Stamp option.

Resolution

Select the image or video resolution from the main menu and choose the required

resolution by pressing the Down button (21), then conrm by pressing the OK button

(20).

Note: This model supports the following image resolutions: 12M, 10M, 8M, 5M, 3M;

video resolutions: 1080P, 720P.

Capture mode

In photo mode, press the Setup button (16) and choose the Capture mode to setup

the sequence capture. For example, you can set up the microscope to take a photo

every 5 seconds.

Loop recording

In video mode, press the Setup button (16) and choose the Loop recording mode.

You can select the duration of the video clip or turn the Loop recording mode o.

While the Loop recording mode is on, each video clip of selected duration will be

recorded over the previous one.

Date Stamp

Select Date Stamp from the main menu and then select a target option.

Date and time

Select Date/Time from the main menu by the Down button (21) and set the current

date and time.

TV connection

Select TV Mode from the main menu and then select, between NTSC and PAL,

the correct mode compatible with your TV. Press the OK button (20) to conrm

selection.

Power saving

Select Auto Power O from the main menu and set the idle time before the

microscope automatically shuts down. Press the OK button (20) to conrm selection.

Settings reset

Select Default Setting from the main menu to revert back to factory settings.

Language

Select Language from the main menu and choose one of the existing settings. Press

the OK button (20) to conrm selection.

MicroSD card formatting

Select Format SD from the main menu to format the installed memory card. All the les

on the card will be deleted aer card formatting. Normally card formatting is not

necessary, unless your card is not able to store the captured image.

PortableCapture soware

Insert the installation CD into your CD drive. Choose the folder according to the

operating system of your device. Double click the installation le to install the

application and follow the instructions on screen. The installation CD contains a

copy of the user manual, which you can nd in the User Manual folder. Connect the

microscope to your PC with a USB cable and run the PortableCapture application.

A pop-up message will warn you if the microscope is not connected to the PC.
