Buffalo WS5400R0804-EU [5/67] Installation

Chapter 1 Installation

Installation

If using OS X 10.4 or later, download and install “Remote Desktop Connection Client for Mac 2” from www.microsoft.

com. For OS X 10.3.9, use version 1.0.3 instead.

1 Connect the supplied USB device to your computer. Open the USB device and double-click TSNavi.exe .

TeraNavigator will launch.

Notes:

• If using Windows 2000 or 2000 Server, make sure that write-protection on the USB device is disabled before con-

necting it. To disable write-protection, slide the switch on the USB device toward the USB connector.

• If “Do you want to allow the following program to make changes to this computer ?” is displayed by Windows 8 or

Windows 7, click Yes. If “A program needs your permission to continue” is displayed by Windows Vista, click Con-

tinue.

• With Mac OS, double-click the disk image “WS5000_SERIES-xxx.dmg” (where xxx is a three-digit number) from the

USB device to mount, and then double-click TeraNavigator in the image.

• Disable your antivirus software firewall before continuing. You may not be able to install the software if antivi-

rus software or a software firewall are enabled. After you’ve finished setup, re-enable your firewall and antivirus

software.

2 Click Begin Installation.

3 Follow the steps on the screen to connect the Ethernet cable and power cable to the TeraStation and turn it on.

Notes:

• Use LAN port 1 for initial setup. After setup, you may connect a second cable to LAN port 2.

• Before removing the sticker on the power connector, be sure to read the terms and conditions of the Microsoft

Software License contained in the “ms-license” folder in the USB device.

4 Follow the steps on the screen to install NAS Navigator2.
