CHEST FREEZER
USER GUIDE USER GUIDE
CHEST FREEZER
* This function means that if your chest freezer was disconnected from the network at a time
when the temperature inside the freezer was maintained at -18 °С, then during the next time (see
the data in the table) the temperature in the chest will rise to -4 °С (provided that the ambient
temperature is not higher than 25 °C.
SPECIFICATION / EQUIPMENT
Model BD(W)-135QX BD(W)-185QX
BD(W)-250QX
BD(W)-250S
BD(W)-310QX
BD(W)-310S
Total volume / Storage volume (L) 135 / 120 185 / 160 250 / 230 310 / 290
Energy efficiency class А А А А
Annual energy сonsumption (kW*h/year) 240 227 259 298
Climate class SN / N / ST ST ST ST
Refrigerant R600a R600a R600a R600a
Power consumption (W) 110 115 125 140
Voltage (V) / Frequency (Hz) 220-240 / 50 220-240 / 50 220-240 / 50 220-240 / 50
Current strength (A) 0,95 1,1 1,45 1,45
Ambient temperature (°С) from - 15 to +43 from - 15 to +43 from - 15 to +43 from - 15 to +43
Winter package option yes yes yes yes
Freezer temperature (°С) to -18 from -14 to -24 from -14 to -24 from -14 to -24
Freezing capacity (kg / day) 5 10 12 17
Freezer mode (°С) yes / -32 yes / -32 yes / -32 yes / -26
Fridge mode — — — yes
Keeping the temperature in case of
power outage (h)*
to 13 to 28 to 32 to 38
Temperature control and regulation way mechanical mechanical mechanical mechanical
Defrosting system manual manual manual manual
Compressor type hermetic hermetic hermetic hermetic
Condenser location internal internal internal internal
Thermal insulation material cyclopentane cyclopentane cyclopentane cyclopentane
Noise level dB(A) 42 40 40 42
Color white white white / silver white / silver
Dimensions
Net / gross weight (kg) 21 / 22 27 / 30 31 / 35 34 / 38
Product dimensions (WxDxH) (mm) 545х480х854 705х550х847 905х550х847 954х616х845
Packing dimension (WxDxH) (mm) 575х495х889 730х570х886 934х570х886 990х640х885
Equipment
Chest freezer (pcs.) 1 1 1 1
Basket (pcs.) 1 1 1 1
Doorhandle integrated integrated integrated integrated
Ice scraper 1 1 1 1
Feets (pcs.) 4 2-2 2-2 4
Manual with warranty card (pcs.) 1 1 1 1
Packing (pcs.) 1 1 1 1
SPECIFICATION / EQUIPMENT
Model
BD(W)-365QX
BD(W)-365S
BD(W)-435QX
BD(W)-435S
Total volume / Storage volume (L) 365 / 340 435 / 410
Energy efficiency class А А
Annual energy сonsumption (kW*h/year) 323 334
Climate class ST ST
Refrigerant R600a R600a
Power consumption (W) 150 155
Voltage (V) / Frequency (Hz) 220-240 / 50 220-240 / 50
Current strength (A) 1,35 1,55
Ambient temperature (°С) from - 15 to +43 from - 15 to +43
Winter package option yes yes
Freezer temperature (°С) from -14 to -24 from -14 to -24
Freezing capacity (kg / day) 21 29
Freezer mode (°С) yes / -26 yes / -26
Fridge mode yes yes
Keeping the temperature in case of power outage (h)* to 40 to 42
Temperature control and regulation way mechanical mechanical
Defrosting system manual manual
Compressor type hermetic hermetic
Condenser location internal internal
Thermal insulation material cyclopentane cyclopentane
Noise level dB(A) 44 42
Color white / silver white / silver
Dimensions
Net / gross weight (kg) 42 / 48 50 / 53
Product dimensions (WxDxH) (mm) 1120х700х845 1300х700х845
Packing dimension (WxDxH) (mm) 1156х748х885 1336х748х885
Equipment
Chest freezer (pcs.) 1 1
Basket (pcs.) 2 2
Doorhandle integrated integrated
Ice scraper 1 1
Feets (pcs.) 4 4
Manual with warranty card (pcs.) 1 1
Packing (pcs.) 1 1
