18 English

Protective clothing

 DANGER

Risk of fatal injury from cut injuries. Wear suitable pro-

tective clothing when working with the device. Observe

the local regulations for accident prevention.

Head protection

When working with the device, wear a suitable safety

helmet that complies with EN 397 and is CE marked.

When working with the device, wear hearing protection

that complies with EN 352-1 and is CE marked.

For protection against flying splinters, wear suitable

safety goggles that comply with EN 166 or are CE

marked. Or wear a helmet visor that complies with EN

1731 and is CE marked.

Protective helmets with hearing protection and a safety

visor are available in specialist shops.

Protective gloves

Wear suitable protective gloves with cut protection

equipment that comply with EN 381-7 and are CE

marked when working with the device.

Safety shoes

Wear non-slip safety shoes that meet EN 20345 and are

CE marked when working with the device.

Description of the device

The maximum amount of equipment is described in

these operating instructions. Depending on the model

used, there are differences in the scope of delivery (see

packaging).

See graphics page for illustrations

Illustration A

1 Chain

2 Guide rail

3 End stop

4 Guide rail pin

5 Bar cover

6 Screw for adjusting the chain tension

7 Chain oil tank cap

8 Upper shaft

9 Twist collar

10 Extension insert

11 Eyelet for carrying belt

12 Lower shaft

13 Handle

14 Battery pack trigger

15 Type plate

16 Trigger

17 Trigger lockout button

18 Carrying belt

19 Allen key for adjusting the chain tension

20 Bar scabbard

21 Chain oil

22 *Battery Pack Battery Power 18V

23 *Quick Charger Battery Power 18V

* optional

Rechargeable battery pack

The device can be operated with a 18 V Kärcher Bat-

tery Power battery pack.

Initial startup

Installing shaft

If required, the device can be extended with the includ-

ed extension insert.

1. Connect the lower shaft and the extension insert.

Illustration B

2. Connect the upper shaft and the extension insert.

Inserting the carrying belt

The carrying belt helps to lower the device in a con-

trolled manner after cutting and to catch the weight of

the device during use.

Illustration C

1. Hook the carrying belt hooks into the eyelets on the

handle and shaft. Place the carrying belt over one

shoulder. Make sure that the carrying belt can be re-

leased quickly in the event of danger.

Filling the chain oil tank

1. If necessary, clean the area around the filling hole of

sawdust and dirt.

2. Remove the chain oil tank cap.

Illustration D

3. Fill the chain oil into the tank. Check the filling level

of the chain oil on the sight glass and make sure that

the chain oil tank is filled to the maximum below the

filling hole.

Illustration E

4. Wipe up any spilled chain oil with a cloth.

5. Close the chain oil tank cap.

Always wear suitable eye protection and

hearing protection when working with the

device.

Do not subject the device to rain or moist

conditions.

Electrical hazard. Keep a minimum dis-

tance of 10 m away from overhead lines

when working with the device.

Danger due to flung objects. Keep spec-

tators, especially children and pets, at

least 15 m away from the work area.

Pull: Quick-release catch

Running direction of the chain

10m
