English 19

Checking the chain tension

몇 CAUTION

Sharp chain

Incision injuries

Wear protective gloves when working on the chain.

1. Remove the bar scabbard.

Illustration F

2. Carefully pull on the chain.

Illustration G

The distance between the guide rail and the chain

must be 3-4 mm.

3. If necessary, adjust the chain tension (see Chapter

Adjusting the chain tension).

Installing the battery pack

1. Push the battery pack into the mounting in the de-

vice until it audibly latches into place.

Illustration H

Operation

Basic operation

1. Examine the tree and branches for damage such as

rot.

In the case of damaged or rotten branches, seek the

advice of a professional arborist.

2. Remove the bar scrabber.

3. Hold the device firmly with both hands.

Switch on the device

1. Press the trigger lockout button.

Illustration I

2. Press the trigger.

The device starts up.

3. Release the trigger.

The device stops.

Working techniques

When pruning, proceed as follows:

 Place the bar on the branch to be cut and push the

device forward so that the end stop touches the

branch.

Illustration J

The device stabilizes during pruning and the cuts

are made cleaner.

 Where possible, maintain a distance of approx. 15

cm between the tree trunk and the cut.

 Cut small branches that are thin and light a single

cut with the bottom edge of the guide rail.

 Heavier branches of larger diameter may break or

splinter during pruning. Therefore, cut in several

steps:

a Make a cut in the underside of the branch with the

top edge of the guide rail. This cut should be

about one third of the branch diameter.

Illustration K

b Make a cut in the top of the branch.

c If another cut is necessary, never continue cutting

in an existing cut but rather start a new cut.

The following should be noted when pruning:

 Do not raise the bar higher than 60 ° from the hori-

zontal.

 Do not exert excessive force on the guide rail.

 Do not stand under the branch being sawn off.

 Make sure that the falling branch does not endanger

the user or spectators nor damage any objects.

 Maintain a safety distance of at least twice the

branch length when pruning. If this is not possible,

have the work done by a professional arborist.

Removing the battery pack

Note

During longer work breaks, remove the battery pack

from the device and secure it against unauthorised use.

1. Press the battery pack unlocking button to unlock

the battery pack.

Illustration L

2. Remove the battery pack from the device.

Finishing operation

1. Remove the battery pack from the device (see

Chapter Removing the battery pack).

2. Clean the device (see Chapter Cleaning the de-

vice).

Transport

몇 CAUTION

Failure to observe the weight

Risk of injury and damage

Be aware of the weight of the device during transporta-

tion.

몇 CAUTION

Uncontrolled startup

Incision injuries

Remove the battery pack from the device before trans-

port.

Transport the device only with the blade guard fitted.

 Secure the device against slipping and tipping over

when transporting in vehicles.

Storage

Clean the device before storing (see Chapter Cleaning

the device).

몇 CAUTION

Failure to observe the weight

Risk of injury and damage

Be aware of the weight of the device during storage.

몇 CAUTION

Uncontrolled startup

Incision injuries

Remove the battery pack from the device before stor-

age.

Store the device only with the blade guard fitted.

1. Remove the carrying belt.

2. Disassemble the shaft into its individual parts.

3. If the device is to be stored for more than one month,

oil the chain to prevent rust.

4. Store the device in a dry, well ventilated location.

Keep away from corrosive substances such as gar-

den chemicals and defrosting salt. Do not store the

device outdoors.

Care and service

몇 CAUTION

Uncontrolled startup

Incision injuries

Remove the battery from the device before all work on

the device.

몇 CAUTION

Sharp chain

Incision injuries

Wear protective gloves when working on the chain.
