20 English

Cleaning the device

1. Remove the battery pack (see Chapter Removing

the battery pack).

2. Use a brush to clean the chain of cutting residue and

dirt.

Illustration M

3. Clean the housing and handles with a soft, dry cloth.

Maintenance work

Before every use

The following activities must be carried out before every

use:

 Check the filling level of the chain oil, top up the

chain oil if necessary (see Chapter Filling the chain

oil tank).

 Check the chain tension (see Chapter Checking the

chain tension).

 Check the chain for sufficient sharpness, if neces-

sary, invert the guide rail or replace the chain (see

Chapter Replacing the chain).

 Check the device for damage.

 Check all pins, nuts and screws for tightness.

Adjusting the chain tension

1. Remove the battery pack (see Chapter Removing

the battery pack).

2. Release the guide rail pin.

Illustration N

3. Adjust the chain tension with the screw.

Illustration O

4. Check the chain tension.

Illustration G

The distance between the guide rail and the chain

must be 3 - 4 mm.

5. Tighten the guide rail pin.

Replacing the chain

1. Remove the battery pack (see Chapter Removing

the battery pack).

2. Remove the guide rail nut.

Illustration P

3. Remove the bar cover and guide rail.

Illustration Q

4. Dispose of the old chain professionally.

5. Fit the new chain on the guide rail.

Illustration R

6. Mount the guide rail. Pay attention to the running di-

rection of the chain.

Illustration S

7. Mount the bar cover, loosely fastening the guide rail

nut.

Illustration T

8. Adjust the chain tension (see Chapter Adjusting the

chain tension).

Troubleshooting guide

Malfunctions often have simple causes that you can

remedy yourself using the following overview. When in

doubt, or in the case of malfunctions not mentioned

here, please contact your authorised Customer Service.

As the battery pack ages, even if it is looked after, its ca-

pacity reduces such that the full run time will no longer

be reached when fully charged. This does not indicate a

defect.

Warranty

The warranty conditions issued by our relevant sales

company apply in all countries. We shall remedy possi-

ble malfunctions on your appliance within the warranty

period free of cost, provided that a material or manufac-

turing defect is the cause. In a warranty case, please

contact your dealer (with the purchase receipt) or the

next authorised customer service site.

(See overleaf for the address)

Technical data

Fault Cause Rectification

The device does not start

Battery pack is empty  Charge the battery pack.

Battery pack is defective.  Replace the battery pack.

Battery pack is not inserted correctly.  Push the battery pack into the mounting

until it latches into place.

The device stops during

operation

Chain blocked by clippings.  Remove the clippings.

The battery has overheated  Stop working and allow the battery to cool

down to normal battery temperature.

Motor has overheated  Stop working and allow the motor to cool

down.

PSW 18-

Device performance data

Working voltage of the battery V 18

Idle speed m/s 5,5

Chain oil tank volume ml 50

Cut material diameter (max.) mm 180

Working range (max.) m 3

Determined values in acc. with EN ISO 11680-1

Sound pressure level L

dB(A) 78,4

Uncertainty K

dB(A) 3

Sound power level L

dB(A) 91,6

Uncertainty K

dB(A) 3
