English 15
5 Battery pack release
6 Telescopic handle
7 Grass catcher filling level indicator
8 Push Assist bracket
9 Starter button
10 ON/OFF switch
11 Motor control cable
12 Handle lock
13 Grass catcher
14 Quick-release catch
15 Rear wheel
16 Mulch plug
17 *Charger
18 *Rechargeable battery pack
19 Safety key
* optional
Rechargeable battery pack
The device can be operated with a 36V Kärcher Battery
Power battery pack.
Initial startup
Adjusting the handle
1. Fold over the telescopic handle out until it audibly
latches into place.
Illustration B
2. Unlock the handle locks.
Illustration C
3. Pull the telescopic handle out completely.
4. Lock the handle locks.
Note
The device only functions when the telescopic handle
has been completely pulled out and the handle locks are
locked.
5. Adjust the inclination angle of the handle if neces-
sary.
a Loosen both quick-release catches.
Illustration D
b Choose the inclination angle.
c Lock the quick-release catches.
Attaching the mulch plug
The mulch plug is used when the mown grass is to re-
main on the lawn.
1. Open the ejection chute flap.
Illustration E
2. Insert the mulch plug into the ejection chute.
3. Close the ejection chute flap.
Installing the grass catcher
The grass catcher is used when the mown grass is to be
collected for disposal.
1. Open the ejection chute flap.
Illustration F
2. Remove the mulch plug.
3. Install the grass catcher on the ejection chute. Take
care to ensure that the ejection chute flap locks the
grass catcher in place.
Illustration G
Installing the battery pack
1. Open the battery flap.
Illustration H
2. Push the battery pack into the mounting in the de-
vice until it audibly latches into place.
3. Insert the safety key.
4. Close the battery flap.
Operation
General information on handling the
lawnmower
The run time of the battery depends on several factors:
● The condition, length and density of the grass
● The cutting height setting
The maximum surface performance, depending on the
state of the grass, with a 5 Ah battery pack:
approx. 650 m
2
.
The results of the mowing process can be optimised as
follows:
● Cut at a maximum of one third of the grass height.
● Reduce the speed at which push the device when
mowing tall grass.
Note
Do not mow wet grass. Wet grass sticks to the under-
side of the lawnmower and prevents correct collection of
the grass in the grass catcher or ejection of the grass.
Mowing lawns
몇 WARNING
Lifting or tipping the lawnmower during operation
Incision injuries
The blade of the lawnmower rotates approximately par-
allel to the ground over which it moves. Take care to en-
sure that all four wheels touch the ground when
mowing.
1. Install the grass catcher or mulch plug (see Chapter
Initial startup).
2. Set the cutting height using the cutting height adjust-
ment lever.
Illustration I
Choose the cutting height according to the condi-
tion, length and density of the grass (see Chapter
General information on handling the lawnmower).
Illustration J
3. Press the start button and the ON/OFF switch.
Illustration K
The device starts.
4. Release the start button and hold the ON/OFF but-
ton pressed.
Empty the grass catcher regularly when using the grass
catcher, otherwise the ejection chute can become
clogged with cut grass (see Chapter Emptying the
grass catcher).
Push Assist function
The Push Assist function activates the device’s self-
driving function.
Note
Only use the Push Assist function on even surfaces. On
gradients or uneven surfaces, you must push the device
as there is a risk that the wheels may start to slip.
The ON/OFF switch is pressed.
1. Press the Push Assist bracket.
Illustration L
The Push Assist function is activated. The device
moves forwards without having to be pushed by the
operator.
