Continued from previous column

M.2 SSD Slot

∙ 2x M.2 slots (Key M)

• M2_1 slot (From CPU)

• Supports up to PCIe 4.0 x4

• Supports 2242/ 2260/ 2280 storage devices

• M2_2 slot* (From B760 chipset)

• Supports up to PCIe 4.0 x4

• Supports up to SATA 6Gb/s

• Supports 2242/ 2260/ 2280 storage devices

* SATA7 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.

RAID

Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA

storage devices

Audio

Realtek® ALC897Codec

∙ 7.1-Channel High Definition Audio

LAN 1x Realtek® RTL8125B 2.5Gbps LAN controller

Power Connectors

∙ 1x 24-pin ATX main power connector

∙ 1x 8-pin +12V power connector

Internal USB

Connectors

∙ 1x USB 3.2 Gen 1 5Gbps connectors (From B760 chipset)

• Supports additional 2 USB 3.2 Gen 1 5Gbps ports

∙ 2x USB 2.0 Type-A connectors (From Hub-GL850G)

• Supports additional 4 USB 2.0 ports

Fan Connectors

∙ 1x 4-pin CPU fan connector

∙ 2x 4-pin system fan connectors

System Connectors

∙ 1x Front panel audio connector

∙ 2x System panel connectors

∙ 1x Chassis intrusion connector

∙ 1x TPM module connector

∙ 1x Serial port connector

Jumpers ∙ 1x Clear CMOS jumper

Continued on next column
