Specifications

CPU

∙ Supports 13th and 12th Gen Intel® Core™ Processors,

Pentium® Gold and Celeron® Processors

∙ Processor socket LGA1700

* Please go to www.msi.com to get the newest support status as new

processors are released.

Chipset Intel® B760 Chipset

Memory

∙ 2x DDR4 memory slots, supporting up to 64GB*

∙ Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)

∙ Max. overclocking frequency:

∙ 1DPC 1R Max speed up to 5333+ MHz

∙ 1DPC 2R Max speed up to 4800+ MHz

∙ Supports Dual-Channel mode

∙ Supports non-ECC, un-buffered memory

∙ Supports Intel® Extreme Memory Profile (XMP)

* Please refer to www.msi.com for more information on compatible memory

Expansion Slot

∙ 1x PCIe x16 slot (From CPU)

• Supports up to PCIe 5.0 x16

Onboard Graphics

∙ 1x HDMI™ 2.1 port with HDR, supports a maximum

resolution of 4K 60Hz*/ **

∙ 1x DisplayPort 1.4 port with HBR3, supports a maximum

resolution of 8K 60Hz*/ **

*Available only on processors featuring integrated graphics.

** Graphics specifications may vary depending on the CPU installed.

SATA Ports

∙ 4x SATA 6Gb/s ports (From B760 chipset)

M.2 SSD Slots

∙ 2x M.2 slots (Key M)

• M2_1 slot (from CPU)

• Supports PCIe 4.0 x4

• Supports 2280 storage devices

• M2_2 slot (from B760 chipset)

• Support PCIe 4.0 x4

• Support SATA 6Gb/s*

• Support 2280 storage devices

* The SATA8 port will be unavailable when installing M.2 SATA SSD into M2_2.

Continued on next column
