Continued from previous column

Internal USB

Connectors

∙ 1x USB 3.2 Gen 2 10Gbps Type-C front panel port (From

B760 chipset)

∙ 1x USB 3.2 Gen 1 5Gbps connector (From B760 chipset)

• Supports additional 2 USB 3.2 Gen 1 5Gbps ports

∙ 2x USB 2.0 connectors (From Hub-GL850G)

• Supports additional 4 USB 2.0 ports

Fan Connectors

∙ 1x 4-pin CPU fan connector

∙ 1x 4-pin water-pump fan connector

∙ 4x 4-pin system fan connectors

System Connectors

∙ 1x Front panel audio connector

∙ 2x System panel connectors

∙ 1x Chassis Intrusion connector

∙ 1x TPM module connector

∙ 1x Tuning controller connector

∙ 1x TBT connector (Supports RTD3)

Jumpers ∙ 1x Clear CMOS jumper

LED Features

∙ 4x EZ Debug LED

∙ 1x 4-pin RGB LED connector

∙ 2x 3-pin A-RAINBOW V2 (ARGB Gen2) LED connectors

Back Panel

Connectors

∙ 4x USB 2.0 Type-A ports (From B760 chipset)

∙ 1x DisplayPort

∙ 1x HDMI™ port

∙ 3x USB 3.2 Gen 2 10Gbps Type-A ports (From GL3590 Hub)

∙ 1x USB 3.2 Gen 2x2 20Gbps Type-C port (From B760

chipset)

∙ 1x 2.5G LAN (RJ45) port

∙ 2x Wi-Fi Antenna connectors

(For MAG B760M MORTAR MAX WIFI DDR4 & MAG B760M

MORTAR WIFI DDR4）

∙ 5x audio jacks

∙ 1x Optical S/PDIF Out connector

I/O Controller NUVOTON NCT6687D Controller Chip

Continued on next column
