Carbon Filter Assembly

Open the product cover and take out the aluminum lter. Turn the carbon

lter in the direction of the arrow by pressing the sides. (see Fig. 1-2)

Flap Assembly

Air Discharge valve prevents the entry of foreign bodies in the engine

group in the installation of the products with a ue. Install the ap as

shown in Figures 3 and 4 by removing the product from the installation

package.

Figure 1

Installation Direction

Figure 2

Direction of Removal

Flap

plastic

Figure 3

Figure 4
