Hardware Installation- 11 -
English
BIOS Use of licensed AWARD BIOS
Supports Q-Flash
Additional Features Supports @BIOS
Supports EasyTune 5 (only supports Hardware Monitor function)
Overclocking Over Clock via BIOS (DDR)
Form Factor Micro ATX form factor; 24.4 cm x 24.4 cm
