![Gigabyte GA-73PVM-S2 (REV. 1.0) [6/100] Box contents](/img/pdf.png)
Gigabyte GA-73PVM-S2 (REV. 1.0) [6/100] Box contents
![Gigabyte GA-73PVM-S2 (REV. 1.0) [6/100] Box contents](/views2/1115140/page6/bg6.png)
- 6 -
• The box contents above are for reference only and the actual items shall depend on product package you obtain.
The box contents are subject to change without notice.
• The motherboard image is for reference only.
Box Contents
GA-73PVM-S2 motherboard
Motherboard driver disk
User's Manual
Quick Installation Guide
One IDE cable
Two SATA 3Gb/s cables
I/O Shield
Optional Items
Floppy disk drive cable (Part No. 12CF1-1FD001-7*R)
2-port USB 2.0 bracket (Part No. 12CR1-1UB030-5*R)
2-port SATA power cable (Part No. 12CF1-2SERPW-0*R)
S/PDIF out cable (Part No. 12CR1-1SPOUT-0*R)
COM port cable (Part No. 12CF1-1CM001-3*R)
