- 11 - Hardware Installation
USB
w
Chipset
- Up to 14 USB 2.0/1.1 ports (10 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
j
- Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
k
IEEE 1394
w
T.I. TSB43AB23 chip
- Up to 2 IEEE 1394a ports (1 on the back panel, 1 via the IEEE 1394a
bracket connected to the internal IEEE 1394a header)
Internal
w
1 x 24-pin ATX main power connector
Connectors
w
1 x 8-pin ATX 12V power connector
w
1 x oppy disk drive connector
w
1 x IDE connector
w
7 x SATA 3Gb/s connectors
w
1 x CPU fan header
w
1 x system fan header
w
1 x front panel header
w
1 x front panel audio header
w
1 x CD In connector
w
1 x S/PDIF In header
w
1 x S/PDIF Out header
w
2 x USB 2.0/1.1 headers
w
1 x IEEE 1394a header
w
1 x serial port header
w
1 x clearing CMOS jumper
Back Panel
w
1 x PS/2 keyboard or PS/2 mouse port
Connectors
w
1 x coaxial S/PDIF Out connector
w
1 x optical S/PDIF Out connector
w
10 x USB 2.0/1.1 ports
j
w
8 x USB 2.0/1.1 ports
k
w
1 x eSATA 3Gb/s port
w
1 x IEEE 1394a port
w
1 x RJ-45 port
w
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/
Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller
w
iTE IT8720 chip
Hardware Monitor
w
System voltage detection
w
CPU/System temperature detection
w
CPU/System fan speed detection
w
CPU overheating warning
w
CPU/System fan fail warning
w
CPU/System fan speed control
(Note 4)
j
Only for GA-P55M-UD2.
k
Only for GA-P55M-US2.
