Gigabyte GA-P55M-UD2 (REV. 1.1) [10/128] 2 product specifications
![Gigabyte GA-P55M-UD2 (REV. 1.1) [10/128] 2 product specifications](/views2/1115152/page10/bga.png)
Hardware Installation - 10 -
1-2 Product Specications
CPU
w
Support for an Intel
®
Core
™
i7 series processor/Intel
®
Core
™
i5 series processor
in the LGA1156 package
(Go to GIGABYTE's website for the latest CPU support list.)
w
L3 cache varies with CPU
Chipset
w
Intel
®
P55 Express Chipset
j
w
Intel
®
H55 Express Chipset
k
Memory
w
4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
(Note 1)
w
Dual channel memory architecture
w
Support for DDR3 2200/1333/1066/800 MHz memory modules
w
Support for non-ECC memory modules
w
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio
w
Realtek ALC888B codec
w
High Denition Audio
w
2/4/5.1/7.1-channel
w
Support for S/PDIF In/Out
w
Support for CD In
LAN
w
1 x RTL8111D chip (10/100/1000 Mbit)
Expansion Slots
w
1 x PCI Express x16 slot, running at x16 (PCIEX16)
(Note 2)
(The PCIEX16 slot conforms to PCI Express 2.0 standard.)
w
1 x PCI Express x16 slot, running at x4 (PCIEX4)
w
2 x PCI slots
Multi-Graphics
w
Support for ATI CrossFireX
™
technology
(Note 3)
Technology
Storage Interface
w
Chipset:
- 5 x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3,
SATA2_4) supporting up to 5 SATA 3Gb/s devices
- 1 x eSATA 3Gb/s connector on the back panel supporting up to 1 SATA
3Gb/s device
- Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10
j
w
GIGABYTE SATA2 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 2 x SATA 3Gb/s connectors (GSATA2_0, GSATA2_1) supporting up to
2 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, and JBOD
w
iTE IT8720 chip:
- 1 x oppy disk drive connector supporting up to 1 oppy disk drive
j
Only for GA-P55M-UD2.
k
Only for GA-P55M-US2.
"*" The GA-P55M-UD2 adopts All-Solid Capacitor design.
