- 11 - Hardware Installation
USB
Integrated in the Chipset
Up to 12 USB 2.0/1.1 ports (6 on the back panel, 6 via the USB brackets con-
nected to the internal USB headers)
IEEE 1394
j
T.I. TSB43AB23 chip
Up to 2 IEEE 1394a ports (1 on the back panel, 1 via the IEEE 1394a bracket
connected to the internal IEEE 1394a header)
Internal
1 x 24-pin ATX main power connector
Connectors
1 x 4-pin ATX 12V power connector
1 x oppy disk drive connector
1 x IDE connector
5 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
1 x S/PDIF In header
1 x S/PDIF Out header
3 x USB 2.0/1.1 headers
1 x IEEE 1394a header
j
1 x serial port header
1 x clearing CMOS jumper
Back Panel
1 x PS/2 keyboard/mouse port
Connectors
1 x D-Sub port
(Note 2)
1 x DVI-D port
(Note 2)(Note 3)(Note 4)
1 x optical S/PDIF Out connector
1 x HDMI port
(Note 2)(Note 4)
1 x DisplayPort
j
(Note 2)(Note 4)
1 x IEEE 1394a port
j
6 x USB 2.0/1.1 ports
1 x eSATA 3Gb/s connector
1 x RJ-45 port
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/
Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller
iTE IT8720 chip
j
Only for GA-H55M-UD2H
