- 12 -Hardware Installation
(Note 1) Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is
installed, the actual memory size displayed will be less than 4 GB.
(Note 2)
To use the onboard D-Sub, DVI-D, HDMI, and DisplayPort
j
ports, you must install an Intel CPU
with integrated graphics.
(Note 3) The DVI-D port does not support D-Sub connection by adapter.
(Note 4)
You can use only one of the onboard digital graphics ports (e.g. DisplayPort
j
, HDMI, and DVI-D)
for output when in the BIOS Setup program or when during the POST screens.
(Note 5) For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install
it in the PCIEX16 slot.
(Note 6) The PCIEX16 slot operates at up to x4 mode when ATI CrossFireX
™
is enabled.
(Note 7) Whether the CPU/system fan speed control function is supported will depend on the CPU/system
cooler you install.
(Note 8) Available functions in EasyTune may differ by motherboard model.
Hardware Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan fail warning
CPU/System fan speed control
(Note 7)
BIOS
2 x 64 Mbit ash
Use of licensed AWARD BIOS
Support for DualBIOS
™
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
Support for @BIOS
Support for Q-Flash
Support for Xpress BIOS Rescue
Support for Download Center
Support for Xpress Install
Support for Xpress Recovery2
Support for EasyTune
(Note 8)
Support for Dynamic Energy Saver
™
2
Support for Smart 6
™
Support Auto Green
Support for Q-Share
Bundled Software
Norton Internet Security (OEM version)
Operating System
Support for Microsoft
®
Windows 7/Vista/XP
Form Factor
MicroATX Form Factor; 24.4cm x 23cm
j
Only for GA-H55M-UD2H
