Gigabyte GA-H55M-S2H (REV. 1.1) [10/96] 2 product specifications
![Gigabyte GA-H55M-D2H (REV. 1.4) [10/96] 2 product specifications](/views2/1115294/page10/bga.png)
- 10 -Hardware Installation
1-2 Product Specications
CPU
Support for Intel
®
Core
™
i7 processors/Intel
®
Core
™
i5 processors/Intel
®
Core
™
i3
processors/Intel
®
Pentium
®
processors in the LGA1156 package
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset
Intel
®
H55 Express Chipset
Memory
2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
(Note 1)
Dual channel memory architecture
Support for DDR3 1666 (O.C.)/1333/1066/800 MHz memory modules
Support for non-ECC memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Onboard Graphics
Integrated in the Chipset:
- 1 x D-Sub port
(Note 2)
- 1 x DVI-D port
(Note 2)(Note 3) (Note 4)
- 1 x HDMI port
(Note 2)(Note 4)
Audio
Realtek ALC888B/892 codec
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF In/Out
Support for CD In
LAN
1 x Realtek RTL8111D/E chip (10/100/1000 Mbit)
Expansion Slots
1 x PCI Express x16 slot, running at x16 (PCIEX16)
(Note 5)
(The PCIEX16 slot conforms to PCI Express 2.0 standard.)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
2 x PCI slots
Multi-Graphics
Support for ATI CrossFireX
™
technology
(Note 6)
Technology
Storage Interface
Chipset:
- 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
JMicron JMB368 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
iTE IT8720 chip:
- 1 x oppy disk drive connector supporting up to 1 oppy disk drive
"*" The GA-H55M-D2H adopts All-Solid Capacitor design.
