Hardware Installation - 10 -
1-2 Product Specications
CPU Support for Intel
®
Core
™
i7 processors/Intel
®
Core
™
i5 processors/
Intel
®
Core
™
i3 processors/Intel
®
Pentium
®
processors/Intel
®
Celeron
®
processors
in the LGA1155 package
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset Intel
®
H61 Express Chipset
Memory 4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
Dual channel memory architecture
Support for DDR3 1333/1066/800 MHz memory modules
Support for non-ECC memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio Realtek ALC889 codec
HighDenitionAudio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN 1 x Realtek RTL8111E chip (10/100/1000 Mbit)
Expansion Slots 1 x PCI Express x16 slot, running at x16
1 x PCI Express x1 slot
(All PCI Express slots conform to PCI Express 2.0 standard.)
4 x PCI slots
Storage Interface Chipset:
- 4 x SATA 3Gb/s connectors (SATA2_0~SATA2_3) supporting up to 4 SATA
3Gb/s devices
Marvell 88SE9172 chip:
- 2 x SATA 6Gb/s connectors (GSATA3_4, GSATA3_5) supporting up to
2 SATA 6Gb/s devices
- Support for SATA RAID 0 and RAID 1
USB Chipset:
- Up to 10 USB 2.0/1.1 ports (6 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
2 x Etron EJ168 chips:
- Up to 4 USB 3.0/2.0 ports (2 on the back panel, 2 via the USB bracket
connected to the internal USB header)
