- 47 - BIOS Setup
Onboard LAN Boot ROM
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
Onboard USB3.0 Controller (Renesas D720200 USB Controller, USB Connectors on
the Back Panel)
Enables or disables the Renesas D720200 USB controller. (Default: Enabled)
USB3.0 Turbo
(
Renesas D720200 USB Controller, USB Connectors on the Back Panel
)
Enables or disables the Turbo USB mode for the Renesas D720200 USB controller. The
actual performance may vary depending on the number of devices being installed. (Default: Disabled)
Onboard Serial Port 1
EnablesordisablestherstserialportandspeciesitsbaseI/Oaddressandcorrespondinginterrupt.
Options are: Auto, 3F8/IRQ4 (default), 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, Disabled.
