- 49 - BIOS Setup
Onboard LAN Boot ROM
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
R_USB30 Controller (
Back Panel
Renesas D720200 USB Controller, USB Connectors
on the Back Panel)
Enables or disables the back panel Renesas D720200 USB controller. (Default: Enabled)
R_USB30 Turbo
(Back Panel Renesas D720200 USB Controller,
USB Connectors on
the Back Panel
)
Enables or disables the Turbo USB mode for the back panel Renesas D720200 USB controller. The
actual performance may vary depending on the number of devices being installed. (Default: Disabled)
F_USB30 Controller (
Front Panel
Renesas D720200 USB Controller, USB Connectors
on the Front Panel)
Enables or disables the front panel Renesas D720200 USB controller. (Default: Enabled)
Onboard Serial Port 1
EnablesordisablestherstserialportandspeciesitsbaseI/Oaddressandcorrespondinginterrupt.
Options are: Auto, 3F8/IRQ4 (default), 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, Disabled.
