- 12 -Hardware Installation
BIOS
w
2x32Mbitash
w
Use of licensed AWARD BIOS
w
Support for DualBIOS
™
w
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
w
Support for @BIOS
w
SupportforQ-Flash
w
Support for Xpress BIOS Rescue
w
Support for Download Center
w
Support for Xpress Install
w
Support for Xpress Recovery2
w
Support for EasyTune
* AvailablefunctionsinEasyTunemaydifferbymotherboardmodel.
w
Support for Dynamic Energy Saver
™
2
w
Support for Smart 6
™
w
Support for Auto Green
w
Support for eXtreme Hard Drive
w
SupportforON/OFFCharge
w
Support for Cloud OC
w
SupportforQ-Share
Bundled Software
w
Norton Internet Security (OEM version)
Operating System
w
Support for Microsoft
®
Windows 7/Vista/XP
Form Factor
w
ATX Form Factor; 30.5cm x 21.5cm
*GIGABYTEreservestherighttomakeanychangestotheproductspecicationsandproduct-relatedinformationwithout
prior notice.
