Gigabyte GA-H61M-USB3-B3 (REV. 1.0) [5/40] Ga h61m usb3 b3 motherboard layout

- 5 -

GA-H61M-USB3-B3 Motherboard Layout

Box Contents

GA-H61M-USB3-B3 motherboard Motherboard driver disk

User's Manual Two SATA cables

I/O Shield

The box contents above are for reference only and the actual items shall depend on the product package you obtain.

KB_MS

VGA_DVI

SYS_FAN

LGA1155

ATX

GA-H61M-USB3-B3

F_AUDIO

COMA

LPT

AUDIO

B_BIOS

M_BIOS

PCIEX16

DDR3_1

DDR3_2

BAT

ATX_12V

Intel

H61

R_USB

USB_LAN

R_USB30

CODEC

iTE

IT8728

CLR_CMOS

F_PANEL

F_USB1F_USB2

CPU_FAN

Atheros

AR8151

PCIEX1

PCI1

PCI2

PCIe to

PCI

Bridge

Etron

EJ168

SATA2_3

SATA2_2

SATA2_1

SATA2_0
