Hardware Installation - 10 -
Internal
Connectors
1 x parallel port header
1 x serial port header
1 x power LED header
1 x chassis intrusion header
1 x clearing CMOS jumper
Back Panel
Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x D-Sub port
1 x DVI-D port
6 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks (Line In/Line Out/Microphone)
I/O Controller iTE IT8728 chip
Hardware
Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control
* Whether the CPU/system fan speed control function is supported will depend on
the CPU/system cooler you install.
BIOS 2 x 32 Mbit ash
Use of licensed AWARD BIOS
Support for DualBIOS
™
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features Support for @BIOS
Support for Q-Flash
Support for Xpress BIOS Rescue
Support for Download Center
Support for Xpress Install
Support for Xpress Recovery2
Support for EasyTune
* Available functions in EasyTune may differ by motherboard model.
Support for Smart 6
™
Support for Auto Green
Support for ON/OFF Charge
Support for Cloud OC
Support for Q-Share
Bundled
Software
Norton Internet Security (OEM version)
Operating
System
Support for Microsoft
®
Windows 7/Vista/XP
Form Factor Micro ATX Form Factor; 24.4cm x 19.5cm
* GIGABYTE reserves the right to make any changes to the product specications and product-related information
without prior notice.
Содержание
- Copyright 4
- Disclaimer 4
- Identifying your motherboard revision 4
- Chapter 1 hardware installation 5
- Chapter 2 bios setup 2 5
- Chapter 3 drivers installation 9 5
- Ga h61m d2 b3 ga h61m s2v b3 motherboard layout ga h61m d2 b3 ga h61m s2v b3 motherboard block diagram 5
- Table of contents 5
- Box contents 6
- Ga h61m d2 b3 ga h61m s2v b3 6
- Ga h61m d2 b3 ga h61m s2v b3 motherboard layout 6
- Ga h61m d2 b3 or ga h61m s2v b3 motherboard 6
- Motherboard driver disk motherboard driver disk two sata cables 6
- The ga h61m d2 b3 adopts all solid capacitor design 6
- User s manual user s manual i o shield 6
- Ga h61m d2 b3 ga h61m s2v b3 motherboard block diagram 7
- 1 installation precautions 8
- Chapter 1 hardware installation 8
- 2 product specifications 9
- 2 productspecifications 9
- 3 installing the cpu and cpu cooler 11
- Installing the cpu 11
- 4 installing the memory 12
- 5 installing an expansion card 12
- Dualchannelmemoryconfiguration 12
- 6 back panel connectors 13
- D sub port 13
- Dvi d por 13
- Line in jack blue 13
- Line out jack green 13
- Mic in jack pink 13
- Ps 2 keyboard and ps 2 mouse port 13
- Rj 45 lan port 13
- Usb 2 1 port 13
- 7 internal connectors 14
- 15 hardware installation 15
- 2 atx_12v atx 2x2 12v power connector and 2x12 main power connector 15
- To meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system 15
- With the use of the power connector the power supply can supply enough stable power to all the com ponents on the motherboard before connecting the power connector first make sure the power supply is turned off and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation the 12v power con nector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start 15
- 4 cpu_fan sys_fan fan headers 16
- Hardware installation 16 16
- Sata2_0 1 2 3 sata 3gb s connectors 16
- The motherboard has a 4 pin cpu fan header cpu_fan a 4 pin system fan header sys_fan most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the motherboard supports cpu fan speed control which requires the use of a cpu fan with fan speed control design for optimum heat dis sipation it is recommended that a system fan be installed inside the chassis 16
- The sata connectors conform to sata 3gb s standard and are compatible with sata 1 gb s standard each sata connector supports a single sata device 16
- F_panel front panel header 17
- Audio signals will be present on both of the front and back panel audio connections simultane 18
- Cord from the power outlet to prevent damage to the usb bracket 18
- Do not plug the ieee 1394 bracket 2x5 pin cable into the usb header 18
- F_audio front panel audio header 18
- F_usb1 2 usb 2 1 headers 18
- Hardware installation 18 18
- Instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer 18
- Ously some chassis provide a front panel audio module that has separated connectors on each wire 18
- Prior to installing the usb bracket be sure to turn off your computer and unplug the power 18
- The front panel audio header supports hd audio by default 18
- The front panel audio header supports intel high definition audio hd and ac 97 audio you may connect your chassis front panel audio module to this header make sure the wire assignments of the module con nector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it 18
- The headers conform to usb 2 1 specification each usb header can provide two usb ports via an optional usb bracket for purchasing the optional usb bracket please contact the local dealer 18
- 19 hardware installation 19
- Coma serial port header 19
- Lpt parallel port header 19
- The com header can provide one serial port via an optional com port cable for purchasing the op tional com port cable please contact the local dealer 19
- The lpt header can provide one parallel port via an optional lpt port cable for purchasing the optional lpt port cable please contact the local dealer 19
- Ci chassis intrusion header 20
- Hardware installation 20 20
- Pwr_led system power led header 20
- This header can be used to connect a system power led on the chassis to indicate system power status the led is on when the system is operating the led keeps blinking when the system is in s1 sleep state the led is off when the system is in s3 s4 sleep state or powered off s5 20
- This motherboard provides a chassis detection feature that detects if the chassis cover has been re moved this function requires a chassis with chassis intrusion detection design 20
- Bat battery 21
- Clr_cmos clearing cmos jumper 21
- 1 startup screen 22
- 2 the main menu 22
- Because bios flashing is potentially risky if you do not encounter problems using the current 22
- Bios setup 22 22
- Chapter 2 bios setup 22
- In the main menu of the bios setup program to upgrade the bios use either the gigabyte q flash or bios utility 22
- Instability or other unexpected results inadequately altering the settings may result in system s failure to boot if this occurs try to clear the cmos values and reset the board to default values refer to the load optimized defaults section in this chapter or introductions of the battery clearing cmos jumper in chapter 1 for how to clear the cmos values 22
- Internet and updates the bios 22
- Q flash allows the user to quickly and easily upgrade or back up bios without entering the operating 22
- Sample bios version ga h61m d2 b3 d13 22
- System bios is a windows based utility that searches and downloads the latest version of bios from the 22
- The following screens may appear when the computer boots 22
- To accept or enter a sub menu 22
- Version of bios it is recommended that you not flash the bios to flash the bios do it with caution inadequate bios flashing may result in system malfunction it is recommended that you not alter the default settings unless you need to to prevent system 22
- 23 bios setup 23
- 3 mb intelligent tweaker m i t 23
- Access more advanced options when the system is not stable as usual select the load optimized defaults item to set your 23
- F11 save cmos to bios 23
- Keys for the main menu only 23
- System to its defaults the bios setup menus described in this chapter are for reference only and may differ by bios 23
- To complete 23
- Version 23
- Whether the system will work stably with the overclock overvoltage settings you made is dependent on your overall system configurations incorrectly doing overclock overvoltage may result in dam age to cpu chipset or memory and reduce the useful life of these components this page is for advanced users only and we recommend you not to alter the default settings to prevent system instability or other unexpected results inadequately altering the settings may result in system s failure to boot if this occurs clear the cmos values and reset the board to default values 23
- Advanced frequency settings 24
- Bios setup 24 24
- M i t current status 24
- This screen provides information on cpu memory frequencies parameters 24
- This section provides information on the bios version cpu base clock cpu frequency memory frequency total memory size cpu temperature vcore and memory voltage 24
- 25 bios setup 25
- Advanced cpu core features 25
- All enables all cpu cores default 25
- Allows you to alter the clock ratio for the installed cpu the adjustable range is dependent on the cpu being installed 25
- Allows you to determine whether to enable all cpu cores 25
- Allows you to determine whether to enable the intel cpu turbo boost technology auto lets the bios automatically configure this setting default auto 25
- Allows you to set a current limit for cpu turbo mode when the cpu current exceeds the specified cur rent limit the cpu will automatically reduce the core frequency in order to reduce the current auto sets the current limit according to the cpu specifications default auto 25
- Allows you to set a power limit for cpu turbo mode when the cpu power consumption exceeds the specified power limit the cpu will automatically reduce the core frequency in order to reduce the power auto sets the power limit according to the cpu specifications default auto 25
- Allows you to set the cpu turbo ratios for different number of active cores auto sets the cpu turbo ratios according to the cpu specifications default auto 25
- Core current limit amps 25
- Cpu clock ratio 25
- Cpu cores enable 25
- Cpu frequency 25
- Displays the current operating cpu frequency 25
- Enables only one cpu core 25
- Enables only three cpu cores 25
- Enables only two cpu cores 25
- Intel r turbo boost tech 25
- Note this item is present only when you install a cpu that supports this feature for more information about intel cpus unique features please visit intel s website 25
- Turbo power limit watts 25
- Turbo ratio 1 core 2 core 3 core 4 core 25
- Bi directional procho 26
- C3 c6 state suppor 26
- Cpu eist functio 26
- Cpu enhanced halt c1e 26
- Cpu multi threadin 26
- Cpu thermal monito 26
- Internal graphics clock 26
- Memory frequency mhz 26
- System memory multiplier spd 26
- 27 bios setup 27
- Advanced memory settings 27
- Allows the system to operate at three different performance levels 27
- Channel interleaving 27
- Displays the memory voltage as 1 v 27
- Dram timing selectable spd 27
- Enables or disables memory channel interleaving enabled allows the system to simultaneously access different channels of the memory to increase memory performance and stability auto lets the bios au tomatically configure this setting default auto 27
- Enables or disables memory rank interleaving enabled allows the system to simultaneously access dif ferent ranks of the memory to increase memory performance and stability auto lets the bios automati cally configure this setting default auto 27
- Extreme lets the system operate at its best performance level 27
- Performance enhance 27
- Profileddrvoltage 27
- Profilevttvoltage 27
- Quick and expert allows the channel interleaving rank interleaving channel a timing settings and channel b timing settings items to be configurable options are auto default quick expert 27
- Rank interleaving 27
- Standard lets the system operate at its basic performance level 27
- System memory multiplier spd memory frequency mhz 27
- The settings under the two items above are synchronous to those under the same items on the ad vanced frequency settings menu 27
- The value displayed here is dependent on the cpu being used 27
- Turbo lets the system operate at its good performance level default 27
- Bios setup 28 28
- Cas latency time 28
- Channel a b advanced timing control 28
- Channel a b standard timing control 28
- Channel a b timing settings 28
- Options are auto default 1 12 28
- Options are auto default 1 15 28
- Options are auto default 1 16 28
- Options are auto default 1 255 28
- Options are auto default 1 31 28
- Options are auto default 1 40 28
- Options are auto default 1 63 28
- Options are auto default 5 15 28
- 29 bios setup 29
- Advanced voltage settings 29
- Channel a b misc timing control 29
- Command rate cmd 29
- Dram voltage 29
- Dynamic vcore dvid 29
- Graphics dvid 29
- Io latency 29
- Mch ich 29
- Options are auto default 1 255 29
- Options are auto default 1 3 29
- Options are auto default 1 31 29
- Pch core 29
- Qpi vtt voltage 29
- Round trip latency 29
- The default is auto 29
- 4 standard cmos features 30
- Access mode access mode sets the hard drive access mode options are auto default chs lba large 30
- Auto lets the bios automatically detect sata devices during the post default manual allows you to manually enter the specifications of the hard drive when the hard 30
- Bios setup 30 30
- Configure your sata devices by using one of the three methods below configure your sata devices by using one of the three methods below 30
- Date mm dd yy 30
- Detection of the device during the post for faster system startup 30
- Determines whether to enable specific streams within the cpu and chipset default enabled 30
- Drive access mode is set to chs 30
- Enables or disables intel virtualization technology virtualization enhanced by intel virtualization tech nology will allow a platform to run multiple operating systems and applications in independent partitions with virtualization one computer system can function as multiple virtual systems default enabled 30
- Ide channel 0 1 master 30
- Isochronous support 30
- Miscellaneous settings 30
- None if no sata devices are used set this item to none so the system will skip the 30
- Note this item is present only when you install a cpu that supports this feature for more information about intel cpus unique features please visit intel s website 30
- Sets the system date 30
- Sets the system time 30
- Time hh mm ss 30
- Virtualization technolog 30
- 31 bios setup 31
- 5 advanced bios features 31
- Access mode access mode sets the hard drive access mode options are auto default large 31
- Allows you to determine whether the system will stop for an error during the post 31
- Auto lets the bios automatically detect sata devices during the post default none if no sata devices are used set this item to none so the system will skip the 31
- Capacity capacity approximate capacity of the currently installed hard drive 31
- Configure your sata devices by using one of the two methods below configure your sata devices by using one of the two methods below 31
- Cylinder cylinder number of cylinders 31
- Default disabled 31
- Detection of the device during the post for faster system startup 31
- Enables or disables the quick boot function to speed up the system boot up process to shorten the wait ing time for entering the operating system and to deliver greater efficiency for daily use the settings here synchronize with the settings of the smart quickboot of smart 31
- Extended ide drive 31
- Halt on 31
- Hard disk boot priority 31
- Head head number of heads 31
- Ide channel 2 3 master 31
- Landing zone landing zone landing zone 31
- Memory 31
- Note this item is present only when you install a cpu that supports this feature for more information about intel cpus unique features please visit intel s website 31
- Options are all errors no errors all but keyboard default options are all errors no errors all but keyboard default 31
- Precomp precomp write precompensation cylinder 31
- Quick boot 31
- Sector sector number of sectors 31
- The following fields display your hard drive specifications if you wish to enter the parameters manually the following fields display your hard drive specifications if you wish to enter the parameters manually refer to the information on the hard drive 31
- These fields are read only and are determined by the bios post 31
- To exit this menu when finished 31
- Cd dvd boot option 32
- Delay for hdd secs 32
- First second third boot device 32
- Hdd s m a r t capability 32
- Init display first 32
- Limit cpuid max to 32
- No execute memory protec 32
- On chip frame buffer size 32
- Onboard vga 32
- Password check 32
- 33 bios setup 33
- 6 integrated peripherals 33
- Allows usb keyboard to be used in ms dos default enabled 33
- Azalia codec 33
- Default 33
- Determines whether to detect usb storage devices including usb flash drives and usb hard drives during the post default enabled 33
- Disabled disabled allows the sata controllers to operate in legacy ide mode 33
- Disabled disabled will turn off all of the usb functionalities below 33
- Enabled 33
- Enables or disables the integrated usb controller default enabled 33
- Enables or disables the onboard audio function default auto 33
- Enables or disables the onboard lan function default enabled if you wish to install a 3rd party add in network card instead of using the onboard lan set this item to disabled 33
- If you wish to install a 3rd party add in audio card instead of using the onboard audio set this item to if you wish to install a 3rd party add in audio card instead of using the onboard audio set this item to disabled 33
- In legacy mode the sata controllers use dedicated irqs that cannot be shared with in legacy mode the sata controllers use dedicated irqs that cannot be shared with other device set this option to disabled if you wish to install operating systems that do not support native mode 33
- Onboard h w lan 33
- Sata port0 1 native mode intel h61 chipset 33
- Smart lan lan cable diagnostic function 33
- Specifies the operating mode of the integrated sata controllers 33
- This motherboard incorporates cable diagnostic feature designed to detect the status of the attached lan cable this feature will detect cabling issue and report the approximate distance to the fault or short 33
- Usb controllers 33
- Usb legacy function 33
- Usb storage function 33
- 7 power management setup 34
- Acpi suspend type 34
- Allows you to decide whether to activate the boot rom integrated with the onboard lan chip 34
- Bios setup 34 34
- Configures the way to turn off the computer in ms dos mode using the power button 34
- Default disabled default disabled 34
- Delay 4 sec delay 4 sec press and hold the power button for 4 seconds to turn off the system if the power button is pressed for less than 4 seconds the system will enter suspend mode 34
- Enables or disables the first serial port and specifies its base i o address and corresponding interrupt options are auto 3f8 irq4 default 2f8 irq3 3e8 irq4 2e8 irq3 disabled 34
- Enables or disables the onboard parallel port lpt and specifies its base i o address and correspond ing interrupt options are 378 irq7 default 278 irq5 3bc irq7 disabled 34
- Instant off instant off press the power button and then the system will be turned off instantly default 34
- Note supported on windows 7 vista operating system only 34
- Onboard lan boot rom 34
- Onboard parallel port 34
- Onboard serial port 1 34
- Parallel port mode 34
- S1 pos s1 pos enables the system to enter the acpi s1 power on suspend sleep state in s1 sleep state the system appears suspended and stays in a low power mode the system can be resumed at any time 34
- S3 str s3 str enables the system to enter the acpi s3 suspend to ram sleep state default in s3 sleep state the system appears to be off and consumes less power than in the s1 state when signaled by a wake up device or event the system resumes to its working state exactly where it was left off 34
- Selects an operating mode for the onboard parallel lpt port options are spp standard parallel port default epp enhanced parallel port ecp extended capabilities port ecp epp 34
- Soft off by pwr bttn 34
- Specifies the acpi sleep state when the system enters suspend 34
- Ac back function 35
- Erp support 35
- Hpet mod 35
- Hpet suppor 35
- Kb power on password 35
- Pme event wake up 35
- Power on by keyboard 35
- Power on by mouse 35
- Power on by ring 35
- Resume by alarm 35
- 8 pc health status 36
- Allows the system to emit warning sound if the cpu system fan is not connected or fails check the fan condition or fan connection when this occurs default disabled 36
- Allows you to determine whether to enable the cpu fan speed control function and adjust the fan speed 36
- Bios setup 36 36
- Case opened 36
- Cpu smart fan control 36
- Cpu system fan fail warning 36
- Cpu warning temperature 36
- Current cpu system fan speed rpm 36
- Current system cpu temperature 36
- Current voltage v vcore ddr15v 12v vtt 36
- Disabled disabled allows the cpu fan to run at full speeds 36
- Displays current cpu system fan speed 36
- Displays current system cpu temperature 36
- Displays the current system voltages 36
- Displays the detection status of the chassis intrusion detection device attached to the motherboard ci header if the system chassis cover is removed this field will show yes otherwise it will show no to clear the chassis intrusion status record set reset case open status to enabled save the settings to the cmos and then restart your system 36
- Keeps or clears the record of previous chassis intrusion status enabled clears the record of previous chassis intrusion status and the case opened field will show no at next boot default disabled 36
- Manual manual allows you to control the cpu fan speed under the slope pwm item 36
- Normal normal allows the cpu fan to run at different speeds according to the cpu temperature you can adjust the fan speed with easytune based on your system requirements default 36
- Reset case open status 36
- Sets the warning threshold for cpu temperature when cpu temperature exceeds the threshold bios will emit warning sound options are disabled default 6 36
- Silent silent allows the cpu fan to run at slow speeds 36
- 10 load optimized defaults 37
- 37 bios setup 37
- 9 load fail safe defaults 37
- Allows you to control the cpu fan speed this item is configurable only when cpu smart fan control is set to manual options are 0 5 pwm value 37
- Auto auto lets the bios automatically detect the type of cpu fan installed and sets the optimal cpu fan control mode default 37
- C 2 0 pwm value 37
- Cpu smart fan mode 37
- Key to load the optimal bios default settings the bios defaults settings help the system to operate in optimum state always load the optimized defaults after updating the bios or after clearing the cmos values 37
- Key to load the safest bios default settings in case system instability occurs you may try to load fail safe defaults which are the safest and most stable bios settings for the motherboard 37
- Note the note the voltage mode can be set for a 3 pin cpu fan or a 4 pin cpu fan however for a 4 pin cpu fan that is not designed following intel pwm fan specifications selecting pwm mode may not effectively reduce the fan speed 37
- Pwm pwm sets pwm mode for a 4 pin cpu fan 37
- Slope pwm 37
- Specifies how to control cpu fan speed this item is configurable only when cpu smart fan control is enabled 37
- Voltage voltage sets voltage mode for a 3 pin cpu fan 37
- 11 set supervisor user password 38
- 12 save exit setup 38
- Again the message password disabled will appear indicating the password has been can celled 38
- Bios setup 38 38
- Supervisor password 38
- The bios setup program allows you to specify two separate passwords 38
- To return to the bios setup main menu 38
- User password 38
- When a system password is set and the when a system password is set and the password check item in advanced bios features is set to setup you must enter the supervisor password for entering bios setup and making bios changes 38
- When the when the password check item is set to system you must enter the supervisor password or user password at system startup and when entering bios setup 38
- When the when the password check item is set to system you must enter the supervisor password or user password at system startup to continue system boot in bios setup you must enter the supervisor password if you wish to make changes to bios settings the user password only allows you to view the bios settings but not to make changes 38
- 13 exit without saving 39
- 39 bios setup 39
- After inserting the driver disk xpress install will automatically scan your system and then list all the drivers that are recommended to install you can click the install all button and xpress install will install all the rec ommended drivers or click install single items to manually select the drivers you wish to install 39
- Before installing the drivers first install the operating system after installing the operating system insert the motherboard driver disk into your optical drive 39
- Chapter 3 drivers installation 39
- The driver autorun screen is automatically displayed which looks like that shown in the screen shot below if the driver autorun screen does not appear automatically go to my computer double click the optical drive and execute the run exe program 39
- To return to the bios setup main menu 39
- Bios setup 44 44
- Contact us 44
- Gigabyte global service system 44
- To submit a technical or non technical sales market ing question please link to http ggts gigabyte com tw then select your language to enter the system 44
Похожие устройства
- Asus ET2230INK-B003R Инструкция по эксплуатации
- Adax NEO NP 12 KDT Red Инструкция по эксплуатации
- Gigabyte GA-H61M-D2P-B3 (REV. 1.0) Инструкция по эксплуатации
- Adax NEO NP 14 KDT Red Инструкция по эксплуатации
- Bookeen Cybook Muse FrontLight (CYBFT1F-BK) Инструкция по эксплуатации
- Gigabyte GA-H61M-D2-B3 (REV. 1.0) Инструкция по эксплуатации
- Bookeen Cybook Odyssey Essential (CYBOY5S-BK) Инструкция по эксплуатации
- Adax NEO NP 20 KDT Red Инструкция по эксплуатации
- Logitech Gaming Keyboard G19S Инструкция по эксплуатации
- Gigabyte GA-X58A-UD9 (REV. 1.0) Инструкция по эксплуатации
- Adax NEO NP 04 KDT Black Инструкция по эксплуатации
- Steelseries 64133 Инструкция по эксплуатации
- Gigabyte GA-X58A-UD7 (REV. 2.0) Инструкция по эксплуатации
- Adax NEO NP 06 KDT Black Инструкция по эксплуатации
- Logitech G700S Инструкция по эксплуатации
- Gigabyte GA-EX58-DS4 (REV. 1.0) Инструкция по эксплуатации
- Adax NEO NP 08 KDT Black Инструкция по эксплуатации
- Plantronics GAMECOM 788 Инструкция по эксплуатации
- Gigabyte G1.SNIPER (REV. 1.0) Инструкция по эксплуатации
- Adax NEO NP 10 KDT Black Инструкция по эксплуатации
Скачать
Случайные обсуждения
