Gigabyte GA-H61M-D2-B3 (REV. 1.0) [12/40] 7 internal connectors
![Gigabyte GA-H61M-D2-B3 (REV. 1.0) [12/40] 7 internal connectors](/views2/1115482/page12/bgc.png)
Hardware Installation - 12 -
1-7 Internal Connectors
Read the following guidelines before connecting external devices:
First make sure your devices are compliant with the connectors you wish to connect. •
Before installing the devices, be sure to turn off the devices and your computer. Unplug the •
power cord from the power outlet to prevent damage to the devices.
After installing the device and before turning on the computer, make sure the device cable has •
been securely attached to the connector on the motherboard.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN
5) SATA2_0/1/2/3
6) F_PANEL
7) F_AUDIO
8) F_USB1/2
9) COMA
10) LPT
11) CI
12) PWR_LED
13) CLR_CMOS
14) BAT
1
2
3
7 9 10
14
4
13
58 6 1211
