- 11 - Hardware Installation
Storage Interface JMicronJMB362chip:
- 2 x eSATA 3Gb/s connectors (eSATA/USB Combo) on the back panel,
supporting up to 2 SATA 3Gb/s devices
- SupportforSATARAID0,RAID1,andJBOD
USB South Bridge:
- Up to 12 USB 2.0/1.1 ports (6 on the back panel, including 2 eSATA/USB
Combo, 6 via the USB brackets connected to the internal USB headers)
1 x Renesas D720200 chip and 2 x VLI VL810 hubs:
- Up to 4 USB 3.0/2.0 ports (2 on the back panel, 2 via the USB bracket
connected to the internal USB header)
* The USB 2.0 signals of the USB 3.0/2.0 ports on the back panel are from the South
Bridge.
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
2 x SATA 6Gb/s connectors
6 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
3 x fan headers
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
3 x USB 2.0/1.1 headers
1 x USB 3.0/2.0 header
1 x clearing CMOS jumper
1 x heatsink LED power connector
Back Panel
Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x optical S/PDIF Out connector
1 x coaxial S/PDIF Out connector
1 x CPU overclocking button
4 x USB 2.0/1.1 ports
2 x USB 3.0/2.0 ports
2 x eSATA/USB Combo connectors
1xRJ-45port
5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker
Out, Line In/Mic In, Line Out)
I/O Controller iTE IT8720 chip
Hardware
Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan fail warning
CPU/System fan speed control
* Whether the CPU/system fan speed control function is supported will depend on
the CPU/system cooler you install.
