User Manual of Network Camera

And the SSL SMTP port is 465.

Enable SSL: Check the checkbox to enable SSL if it is required by the SMTP

server.

Attached Image: Check the checkbox of Attached Image if you want to send

emails with attached alarm images.

Interval: The interval refers to the time between two actions of sending attached

pictures.

Authentication (optional): If your email server requires authentication, check

this checkbox to use authentication to log in to this server and enter the login

user Name and password.

Choose Receiver: Select the receiver to which the email is sent. Up to 2 receivers

can be configured.

Receiver: The name of the user to be notified.

Receiver’s Address: The email address of user to be notified.

4. Click to save the settings.

6.6.7 Configuring Snapshot Settings

Purpose:

You can configure the scheduled snapshot and event-triggered snapshot. The

captured picture can be stored in the SD card (if supported) or the netHDD (For

detailed information about netHDD, please refer to Section 7.1 Configuring NAS

Settings). You can also upload the captured pictures to a FTP server.

Basic Settings

Steps:

1. Enter the Snapshot Settings interface:

Configuration > Advanced Configuration > Events > Snapshot

2. Check the Enable Timing Snapshot checkbox to enable continuous snapshot.

Check the Enable Event-triggered Snapshot checkbox to check event-triggered

snapshot.

3. Select the quality of the snapshot.

4. Set the time interval between two snapshots.

5. Click to save the settings.

Uploading to FTP

You can follow below configuration instructions to upload the snapshots to FTP.

 Upload continuous snapshots to FTP

Steps:

1) Configure the FTP settings and check checkbox in FTP

Settings interface. Please refer to Section 6.3.8 Configuring FTP Settings for more
