Alcatel ONETOUCH X600 [5/12] Profile management

 Active profile: Select the profile you want to use from the drop down box.

 Connection Status: display the network is connected or disconnected;

 Usage: Display usage data

 Duration: the duration for current connection;

WAN status

 Network name: the network name you are using;

 Network type: GPRS/EDGE/UMTS/HSDPA/HSUPA/HSPA+

 Roaming: display whether you are in roaming network or not;

 IP address: this is the IP address arranged for this device.

3.2 Profile management

Add a new profile:

1, Click <New>.

2, Input the correct parameters you get from the operator.

Note: Profile Name/Number/APN is the mandatory to be filled.

3, Click <Save>.

Edit a profile:

1, Select the profile from the connection profile list.

2, Change the parameters.

3, Click <Save>.

Delete a profile:

1, Select the profile from the connection profile list.

2, Click <Delete>.

3, On the pop up dialog ”are you sure to delete this profile?”,click <OK>.

Note: the default profile can not be deleted.

Set as default:

1, Select the profile from the connection profile list.

2, Click <Set default>.

3, On the pop up dialog ”are you sure to set this profile as default?”, click <OK>.

Note: Once set the profile as default,(D) will be added as a mark.

3.3 Network

 Network Mode:Automatic/3G only/2G only, default is automatic.

 Network Selection: Automatic/Manual, default is automatic.

Select a Network Manually
