14 © SAMSUNG Electronics Co., Ltd.

To use as wall-mounted phone, the position of the handset hanger must be changed

to prevent the handset from being dropped. Take out the handset hanger, change the

hanger’s direction and insert again.

The above figure shows ITP-5121D as a sample. If you purchase ITP-5114D/ITP-

5107S, the relevant phone is included.
