Introduction
Design, technology and power: as a HERTZ tradition, many innovations were developed to
enhance the Hi-Tech edge of the HP line:
- D-class technology has been introduced in the HP monoblocks providing incredible power
with high efficiency;
- HP MANAGER microprocessor based monitoring system digitally manages the operating
status of the amplifier and transfers this information to the user through a stunning blue LCD
display and LED indicators
- HP IN provides the ability to interface HP amplifiers with both OEM or aftermarket source units
- HP LINK & HP LINK 2 allows to configure two HP 1 into a bridged (strapped) mode, perfectly
synchronizing the amplifiers to extract their maximum power output, up to 6600W (RMS) into
a 2ohms load for the ultimate performance in SPL competition
Five models are available to satisfy the demands of car audio enthusiasts.
HP 1KD and HP 1D
3200W (RMS) and 2300W (RMS) D-class monoblocks.
The amplifiers for the hungriest subwoofer sections.
HP 2:
1300W (RMS) AB class two-channel provides 600W (RMS) x 2 (2ohms) for driving high power
front/rear/multi-amplified systems with 1200W (RMS) bridged mono power for subwoofer
applications.
HP 4:
920W (RMS), AB class four-channel offers 230W (RMS) x 4 (2ohms) for front + rear applications,
or bridged into 3-channel mode to drive front + mono subwoofer designs thanks to well thought
out configuration functions.
HP 5:
980W (RMS) AB class five-channel design, 120W (RMS) x 4 (2ohms) + 500W (RMS) x 1 (2ohms)
represents the best solution for complete front + rear + subwoofer systems or a bi-amplified front
system plus subwoofer.
HERTZ HP:
For those searching for an amplifier with the power to create the impact of a live performance; an
amplifier with the sound quality to stir your emotions.
Design, Technology and Power… Our goal has been achieved!
Table of contents
Introduction 38
Table of contents 39
Packing contents 40
Safe Sound 41
General precautions 42
Input Panel 44
Power Supply/Outputs/Other Functions Panel 45
Other functions 46
Auto Turn ON 46
Control Panel 46
HP 2 Out Mode 47
HP 2 Filter Configurations 47
HP 2 Input / Output Configurations 47
HP 4 Out Mode 48
HP 4 Filter Configurations 49
HP 4 Input / Output Configurations 49
HP 2 Filter 50
HP 4 Filter 51
HP 4 Levels 53
HP Manager 54
LCD Statud Display 54
Diagnostic LED descriptions 55
Installaton 56
Amplifier fixing 56
Mounting Template 56
How to open/close the control panel 57
How to replace the fuse 58
High Level Input (SPEAKER IN) 58
Power Terminals 59
Connection cables 60
Speaker cable recommendations 60
Power and Ground cable recommendations 60
Pattern 61
Configuration diagrams 62
Technical specifications 69
Block diagram 70
Italiano | English
38 39
