Toughpower
CableManagement 1000W ATX12V 2.2 & EPS 12V 2.91 Version
Toughpower
CableManagement 1000W ATX12V 2.2 & EPS 12V 2.91 Version
1.2 Warnings and Cautions
2. Product Features
1.2.1 Do not pull the AC power cord when the power supply is
in use or the damages to the components will occur.
1.2.2 Do not store the Power Supply in high humidity and high
temperature environment.
1.2.3 When usin
power supply under testing conditions where the power
supply unit is not installed in a PC with its components,
please follow the steps below:
1) Please take a paper clip and untwist it.
2) Make sure the power supply unit is in the "OFF"
position.
3) Locate the 20+4 pin motherboard connector from the
power supply unit.
4) Plug one side of the paper clip into the green wire hole.
5) Plug the other side of the paper clip into any of the
black wire holes.
6) Turn on the PSU to see if the power supply fan(s)
turn(s) on.
1.2.4 High voltages exist in the power supply. Do not open the
power supply case unless you are an authorized service
technician or electrician.
1.2.5 All warrantees and guarantees shall be voided should
there be a failure to comply with any of the warnings and
cautions covered in this manual.
g Toughpower Cable Management 1000W
2.1 NEW 8 pin PCI-E Connector
Toughpower 1000w power supplies come with three of the
latest 8-pin PCI-E connectors required for the next
generation NVIDIA and ATI graphics cards. These new
defined 8-pin connectors are downward compatible with
the existing 6-pin PCI-E connectors with an 8 pin to 6 pin
converter. Thus, with the included three 6-pin/8-pin
connectors, Toughpower 1000W support up to three high-
end graphic cards.
2.2 Excellent Efficiency (up to 87%)
Toughpower 1000W provide excellent efficiency and hence
reducing energy consumption. That in return reduces
customers electricity bill.
2.3 140mm Ball-Bearing Fan
The 140mm ball bearing fan effectively increases the
airflow inside the PSU and decreases the ambient
temperature.
2.4 Extremely good voltage regulation ( 3%)
This feature allows tighter load regulation ( 3%) than other
power supplies ( 5%) and increase system voltage
stability.
2.5 MTBF > 120,000 hours (Highly reliable)
120,000 hours of MTBF (Mean Time between Failures)
goes above and beyond all ATX specifications.
02
03
297X 210 mm
