9.Trouble Shooting
Condition 1:
No DC output. The fan or fans are motionless. Check:
1-1 Is the AC inlet plug firmly plugged into the PSU inlet
socket?
1-2 Is the wall socket, extension power cord, power strip
or surge protector in use, fully functional and wall
power switch turned ON ?
1-3 Is the Main Board socket (20+4 pin) plug fully and
firmly inserted?
Condition 2:
The fan or fans began rotating and then stopped. The
system hangs without proceeding any further Check:
2-1 Are the peripheral connectors firmly plugged into
accessory devices, such as the main hard drive, CD
ROM, etc?
2-2 If a plug has been inadvertently connected in an off-
set or reversed position, unplug the AC power source,
reconnect the offending connectors and then wait for
30 seconds before replug in the AC power source and
try again.
Note: If the power supply is still unable to power up after following the
above instruction, please send the unit back to your dealer or retailer
for after sales service.
10. Contact us
For further technical supports or general inquiries,
please contact us at:
Toll Free: (800)988-1088
Email: support-usa@thermaltake.com
Thermaltake Europe B.V.
Tel:+31-10-409-0150
Email: tt.europe@thermaltake.com
Thermaltake Germany GmbH
TEL: +49 (0) 40-308-5860
E-MAIL: support@thermaltake.de
Thermaltake Beijing Co.Ltd.
Tel:+86-10-82883159/3189 ext.16
Email: doctort@thermaltake.com.cn
Thermaltake Australia and
New Zealand Pty Ltd
Tel:+613-9763-1622
Email: sales@thermaltake.com.au
Thermaltake Japan Inc.
Email: sales-jp@thermaltake.co.jp
Thermaltake Technology USA
