Thermaltake Toughpower 1350W [3/28] Installation steps
![Thermaltake Toughpower 1350W [3/28] Installation steps](/views2/1118367/page3/bg3.png)
Toughpower 1350W Toughpower 1350W
1. Do not unplug the AC power cord when the power supply is in use. Doing so may
cause damage to your components.
2. Do not place the power supply in a high humidity and/or temperature environment.
3. High voltages exist in the power supply. Do not open the power supply case
unless you are an authorized service technician or electrician. Doing so will void
the warranty.
4. PSU should be powered by the source indicated on the rating label.
5. Please use only genuine Thermaltake modular cables with Thermaltake
Toughpower 1350W Cable Management power supply models. Third party cables
might not be compatible and could cause serious damage to your system and
power supply. The warranty is voided with the use of third party cables.
6. All warrantees and guarantees will be voided, if failure to comply with any of the
warnings and cautions covered in this manual.
1. Warnings and Caution
2. Components Check
- Toughpower 1350W power supply unit - Mounting screws x 4
- Modular cable set - Cable straps x 4
- User manual - Thermaltake Aluminum Badge
- AC power cord
3. Power Connector Introduction
NOTE: Floppy connector is attached to the end of the peripheral cable.
ATX Cable (24-pin)
EPS12V CPU Cable (8-pin)
ATX/EPS 12V CPU Cable (4+4pin)
PCI-E Cable (6+2pin)
SATA Cable
Peripheral Cable
Peripheral Cable to PCI-E 6pin adapter
Peripheral Cable to PCI-E 8pin adapter
1
1
1
6
12
8
1
1
550mm
550mm
550mm
550mm
550mm
550mm
100mm
100mm
1
1
1
1
3
2
1
1
Type
QTY
Length
Cable
4. Installation Steps
Note: Make sure that your system is turned off and unplugged. Disconnect the AC power
cord from your old power supply.
1. Install the PSU into the case with the four screws provided.
2. Connect the 24-pin Main Power Connector to your motherboard.
3. For motherboard that only requires a 4pin ATX 12V (CPU) connector, please detach a
4pin connector from the 4+4pin ATX 12V connector and connect it to the motherboard.
(Either one of the 4pin from the 4+4pin ATX 12V connector will work)
4. Connect the modular cables from the cables accessories pack to the socket on the power
supply as needed
5. Connect the SATA devices (if applicable) to the power supply using the SATA cables
provided. ie; hard drives, CD/DVD drives
6. Connect any devices that may use the 4 pin peripheral connectors. ie; hard drives,
CD/DVD drives or case fans.
7. If your graphic card requires PCI-E power connector, please connect corresponding PCI-
E connector instructed by your graphic card’s user manual. Please note the power
supply utilizes a unique 6+2pin PCI-E connector that can be effectively used as a single
8pin or 6pin PCI-E connector. To use it as a 6pin PCI-E connector, please detach the
2pin connector from the 6+2pin connector.
DO NOT PLUG THE PCI-E CABLE INTO THE CPU POWER CONNECTION.THIS WILL
DAMAGE YOUR SYSTEM.
8. Connect the AC power cord to the power supply AC inlet and turn the switch to “I” position
5. Product Features
- Compliance with Intel ATX 12V 2.3 & SSI EPS 12V 2.91 standards.
- 24 / 7 @ 50℃: Guaranteed to deliver 1350W continuous power.
- 80 PLUS Silver certified – with 87-91% efficiency @ 20-100% load under real world load
conditions.
- Double-forward switching circuitry offers low power loss and high reliability.
- Unparalleled DC to DC converters for 3.3V and 5V outputs to reach high efficiency.
- Robust and dedicated dual +12V rails(60A for 12V1 & 12V2) design provides superior
performance under all types of system loading.
- High quality 105°C Japanese capacitors: ensure superb performance and reliability.
- 105°C Solid state capacitors: great stability at higher operating temperatures, frequencies
and currents.
- Multi-GPU ready: 8 x PCI-E connectors for PCI-Express graphic cards.
- Designed to support quad core, Core i7 and Core i5 CPUs.
- Active Power Factor Correction (PFC) with PF value of 0.99 at 20%, 50% and 100% loading.
- Ultra-silent operation with intelligent 14cm cooling fan speed control.
- High reliability: MTBF>120,000 hours.
- Dimensions: 150mm(W)x86mm(H)x200mm(L).
- Built-in industry grade protections: Over Current, Over Voltage, Under Voltage, Over power,
Over temperature and Short-Circuit protection.
- Safety / EMI Approvals: CE, TUV, FCC, UL, CUL, GOST, and BSMI certified.
0201
