Soundmax SM-LCD811 [6/17] Installation and connection

Power Selection

1. Power adaptor: AC adapter supplies power to the television from 220V

alternating current.

2. Car adaptor: The car adaptor (please use the included device only)

allows the TV to be powered by a car battery through the vehicle's

cigarette lighter.

Installation and connection

Installation of Stand:

Insert the fixing part of the stand into the gutter of the bracket on the rear of

the unit. Tighten the plastic fixing screw.

Connection of power supply:

Insert the plug of the Power adaptor or Car adaptor into the power jack of the

unit. Connect the adaptor to the power source.

Earphone connection:

Connect the earphone plug to the phone (line in) jack of the unit.

Note: If earphone is applied, the sound only transmits through the earphone,

and no sound is available from the speaker of the TV set.

Connection of external antenna:

Insert one end of the external TV antenna or cable antenna cord plug to the

antenna jack of the unit.

Connection of audio-video jack:

Insert one end of the included audio-video cable into the Audio/video in

(MMI) jack of the unit. Connect the other ends of the cable (yellow for

video/red and white for audio) to corresponding terminals of an external

device, such as VCD or DVD player etc.

In order to receive a clearer picture

Adjust the length, angle and direction of the telescopic antenna to obtain

optimum image. Collect the antenna after usage.
