Mtx RT1000.1D [2/48] Owner s manual rt1000 d

SPEAKER

+ +

- -

GNDREM+12V

POWER

INPUT OUTPUT

GAIN

X-OVER

SUB

SONIC

EBC Port

40Hz 180Hz6V 0,1V OFF 50Hz

www.mtxaudio.com - www.mtxaudio.eu

Introduction

Thank you for purchasing an MTX Audio Hi-Performance ampliﬁer. Proper installation matched with MTX speak-

ers and subwoofers provide superior sound and performance for endless hours of waking the neighbors, slam-

min' your friends or ﬂat out stomping wanna-be players. Congrats and enjoy the ultimate audio experience with

MTX !

Speciﬁcations

• 1-Channel Mono Block Class-D Power Amplier

• CEA2006 certied Power Output :

- 1000 watts RMS x 1-channel at 2Ω and THD+N ≤1%

- 600 watts RMS x 1-channel at 4Ω and THD+N ≤1%

• Crossover :

- Low pass 12dB/oct variable from 40Hz to 400Hz

- Subsonic lter 12dB/oct variable from 0 to 50Hz

• Signal-to-Noise Ratio (1 watt) : > 80dB

• THD+Noise (Distortion) (1 watt) : ≤ 1%

• Frequency Response (±1dB) : 20Hz-30000Hz

• Maximum Input Signal : 6V

• Maximum Sensitivity : 100mV

• Dimensions : 456mm x 180mm x 55mm

• EBC (External Bass Control) remote included

Control Panel

Owner’s Manual - RT1000.1D
