11
E
Instrument panel (fig. 3)
1) Speedometer (km/h or mph).
Gives road speed.
a) Odometer (km or miles).
Gives total distance covered.
b) Trip meter (km or miles).
Gives distance covered since last resetting.
c) Trip meter resetting knob.
Turn to reset trip meter to “0000”.
2) Engine revolution meter (rpm)
Indicates engine rpm.
3) Green light N.
Comes on when gearbox is in neutral.
4) Yellow light .
Comes on when there are about 4 liters (1.05 US Gall.)
fuel left in the tank.
5) Green light .
Comes on and flashes when a turn indicator is on.
6) Red light .
Comes on when engine oil pressure is too low. It comes
on when the ignition is switched to ON and normally
goes out a few seconds after engine starts.
Important
If this light (6) stays on, stop the engine or it may
suffer severe damage.
7) Blue light .
Comes on when right high beam is on.
8) Water temperature indicator .
Indicates engine coolant temperature.
5a
1
c
b
8
3 7 4 2 6
fig. 3
Important
Stop riding if the temperature reaches the max.
value, otherwise the engine might damage.
When parking light is on, the instrument panel is lighted.
