38
E
MAIN MAINTENANCE OPERATIONS
Removing the fairing
Some servicing operations need the motorcycle fairing to
be removed.
Warning
Firmly secure all removed parts when refitting
them, otherwise some of them might suddenly come off
when riding and you may loose control of your
motorcycle.
Important
At reassembly always fit nylon washers when
tightening fastening screws, not to damage painted parts
and Plexiglas headlamp fairing. Some fastening screws
are of the self-tapping type; do not overtighten,
otherwise treading might damage thus avoiding further
use.
fig. 25
Side body panels (fig. 25)
To remove the body panels proceed as follows:
disconnect the two connectors (1) joining the two body
panels together;
disconnect the four headlamp fairing connectors (2);
disconnect the four frame connectors (3).
